Page 16 ams Datasheet
Document Feedback [v1-01] 2015-Oct-12
AS-MLV-P2 − Mechanical Information
Figure 18:
Tape and Reel Information
Description Items Symbol Value Unit Tolerance
Pocket
Length Ao 9.70
mm ±0.10
Width Bo 9.70
Depth Ko 5.00
Pitch P1 12.00
Angle θ1 3
Degree Max.
Angle θ2 3
