Aviator 5 Installation Instructions Compatible with works with the Google Assistant
Please read and review instructions before installation
02 02 General Inquiries For all questions about your ceiling fan please read all included instructions, installation procedures, troubleshooting guidelines and warranty information before starting installation Fan Support For fast service have the following information below when you call: For missing parts or general inquiries call our trained technical staff at: • • • 1-866-810-6615 1-866-810-6615 option 0 Mo de l Name and Numbe r Part Numbe r and Part D e sc ri pti o n D ate Of Purc hase and Pu
02 Safety Rules For operation, maintenance, and troubleshooting information, visit modernforms.com/help. 1. To reduce the risk of electric shock, ensure electricity has been turned off at the circuit breaker before beginning. 2. All wiring must be in accordance with the National Electrical Code “ANSI/NFPA 70” and local electrical codes. Electrical installation should be performed by a licensed electrician. 3.
02 WARNING: Do not install or use your fan if any part(s) is/are damaged or missing. This product is designed for use only with the supplied parts and/or accessories designated for use with this product by Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern Forms could result in personal injury or property damage and will void the warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
02 Get Smart All Modern Forms Smart Fans are: WET DC MOTOR Durably finished and rated for interior and exterior use Wet location-listed to the strictest UL/cUL safety regulations Coordinate with smart devices for voice-activated control Quiet, reliable, and up to 70% more efficient than AC fans Wi-Fi and Bluetooth enabled for flexible control Compatible with our free Modern Forms app The Modern Forms app integrate seamlessly with smart home devices you already own works with the Google Assistant
Table of Contents 4 Package Contents 9. 5 Mounting Options 10. 5 Installing the Mounting Bracket 10. 6 Attaching the Fan Blades 11. 7 Attaching Decorative Lower Cap 12. 8 Hanging the Fan 13. 8 Making the Electrical Connections 14. 9 Installing the Wall Control 15. 10 Finishing the Installation 17. 11 Installing the Luminaire Module (Optional Accessory) 18. 12 Controlling the Fan 20. 13 Factory Reset 21. 14 App Instructions 22. 15 Accessories 24.
03 Tools & Materials Required Phillips screwdriver Step ladder Wire cutters Electrical tape NOTE: Before discarding packaging materials, be certain all parts have been removed. NOTE: Place the parts from the hardware bag into a small container to keep them from being lost. MAC ID IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place.
Package Contents Fan Blade 3 2 5 Downrod Assembly RPL-HGR-ASM-** 1 7 RPL-F1811-70-BD-** 4 Mounting Bracket RPL-CAN-CYL-** Blade Collector Ring 6 Luminaire Module (optional) Canopy Ring Motor Housing RPL-HGR-ASM-** 10 12 04 8 Coupling Cover 14 Decorative Lower Cap Canopy RPL-CAN-CYL-** Wall Control F-WCBT-WT 15 F4IN-120V-R1-30 Hardware Bag RPL-F1811-70-PARTS 9 Adapter Plate (optional) 13 11 Glass Shade (optional) RPL-F1811-70-GLA Receiver F-R3-1811-070 Safety Cable 6.
05 Mounting Options 1 2 Standard Ceiling 10 Installing The Mounting Bracket Slope Ceiling Caution: Remember to disconnect the power at the circuit breaker. CAUTION: To prevent electrical shock, ensure electricity has been turned off at the circuit breaker before beginning. 1. Remove 1 set screw from mounting bracket and set aside for use in Finishing the Installation. Figures 1 and 2 are examples of different ways to mount the outlet box. 2.
Attaching the Fan Blades 3 1. Place blade on motor and secure with the blade attachment, screws and washers. 06 4 4. Remove set screws from motor housing, install blade collector ring (when applicable), and re-install screws. 2. Insert blades in slots, aligning with motor assembly holes. 3. Secure blades with blade attachment screws & washers.
07 Attaching Decorative Lower Cap 5 1. Install decorative lower cap adapter as shown. 12 6 1. Install decorative lower cap.
Hanging the Fan 7 08 8 1. Remove screw from hanger ball. Remove hanger ball and cross pin. 1. Install coupling cover, canopy screw ring, canopy and downrod assembly into motor housing as shown. 2. Loosen 2 screws, clevis pin and cotter pin. 2. Align downrod and motor collar holes, re-insert pins and screws. 3. Slip up canopy and canopy screw cover. Re-install hanger ball with cross pin in correct place.
08 Hanging the Fan 9 Making the Electrical Connections 10 OUTLET BOX BLACK (HOT) BLACK (“AC IN L”) RECEIVER RED (TO MOTOR) GRAY (TO MOTOR) YELLOW (TO MOTOR) YELLOW (MOTOR) GRAY (MOTOR) RED (MOTOR) 1. Seat all into the mounting bracket. Rotate until ball drops and locks into hanger bracket screw. 2. Secure safety cable to structure.
Installing the Wall Control 09 11 White White Black (to fan) Red Black (from breaker) Black Copper Green (Ground) Ground White (Neutral) Wall outlet box Wall control NOTE: For multi-location wiring, skip to the next step. 1. Connect the green wire marked “GROUND” from the wall control to the copper wire from the wall outlet box that feeds back to the circuit breaker – important for proper fan function. 2.
09 Installing the Wall Control 12 if Applicable Wall Controller 1 Wall Controller 2 Wall Controller 3 White to Fan Black to Fan HOT IN Green White Red Black Green White Red Black Green White Red Black Green to Fan Green 1. Install the wall control using the wiring diagram in below. 2. Individually pair each of the wall controls with the fan receiver using the pairing instructions in section 20.
Finishing the Installation 13 1. Secure wire connectors with supplied wire ties. 10 14 1. Install canopy screw ring as shown. 2. Install canopy to mounting bracket with the screw removed in section 5.
11 Installing the Luminaire Module (Optional Accessory) 15 16 1. To install luminaire module, remove decorative lower cap. NOTE: If you are not installing the luminaire module skip to step 18. 2. Remove 1 of 3 screws and loosen the others (do not remove). 1. Attach LED wires from motor assembly to luminaire module. 3. Using the screw from the previous step, install the adapter plate. 2. Install glass shade without over-tightening.
Installing the Luminaire Module (Optional Accessory) 17 1. Secure the luminaire module with the 3 screws to the adapter plate. FR- W1 8 1 1 11 18 1. Install glass shade without over-tightening.
12 Controlling the Fan 19 20 21 A Summer Mode B C (Counter-Clockwise) Air-Gap Switch* Wall Control Remote Pairing Unpairing * Air-Gap Switch only included Control Press and hold buttons To purge, press and hold buttons for 4 seconds. with wall control for 10-15 seconds. Your fan is pre-paired. If you need to pair your fan refer to step 20.
Factory Reset 22 23 Fan Wi-Fi Reset Press and hold the and buttons until the 24 Factory Reset Receiver Factory Reset Press and hold buttons for 10 seconds Press the reset button on the receiver LED blinks green and the receiver beeps NOTE: Changes to your Wi-Fi network settings (SSID or Security Passphrase) will prevent your fan from connecting to the cloud.
14 Application In addition to the included wall control, you can control your fan with the remote control (sold seperately) or through the Modern Forms app. 1. To use the Modern Forms app, download it for free from the App Store or Google Play. 2. Open the app to create your account. You can also log in using your Facebook or Google account. 3. To set up a Wi-Fi connection you will need the SSID and Wi-Fi password for the network you wish to connect to. 4.
Application 5. 14 The Modern Forms app will walk you through the main screen and show you how to create schedules, change fan speeds, dim the light, switch between Summer and Winter Modes, invite users, create groups and much more. Please refer to the Modern Forms app instructions for more details.
15 Accessories Product Wi-Fi Touch Panel Wall Control Bluetooth Wall Control Model F-TS Description Full app control Sold separately Finish BK, WT 6 fan speeds, dims light to 1% F-WCBT-WT Works in conjunction with Modern Forms WT Smart Fan receiver (not included) Coupler 24 XF-I Slope Ceiling Kit XF-SCK Bluetooth Remote Control F-RCBT-WT Connects two downrods Designed to accommodate buildings with steeper sloped ceilings up to 45° or 12/12 pitch Compatible with Modern Forms Smart Fan
Accessories Product Model Description 12” in downrod AS, BA, BN, BZ, CFI, GB, GH, GW, KO, MB, MW, OB, SS, TT XF-18 18” in downrod AS, BA, BN, BZ, CFI, GB, GH, GW, KO, MB, MW, OB, SS, TT XF-24 24” in downrod AS, BA, BN, BZ, CFI, GB, GH, GW, KO, MB, MW, OB, SS, TT XF-36 36” in downrod All our downrods are 1” O.D.
Certificate of Warranty Congratulations on your new purchase. Your new Modern Forms Smart Fan is engineered to make life easier every day. Modern Forms creates future-forward fans and luminaires that provide energy savings and outstanding efficency. Our dedication to doing things the right way goes beyond our love for amazing products.
Félicitations pour votre nouvel achat. Votre nouveau ventilateur intelligent Modern Forms est conçu pour vous simplifier la vie au quotidien. Modern Forms crée des ventilateurs et des luminaires d’avant-garde qui permettent des économies d’énergie et une efficacité exceptionnelle. Notre engagement à bien faire les choses va au-delà de notre amour pour les produits étonnants.
