Additional Conguration Options3.6.3
Administering the camera: • You can modify the camera configuration in the Administration
menu or the Setup menu.
• Admin Menu: This menu contains the basic configuration dialogs of the camera
(e.g. passwords, interfaces, software update).
• Setup Menu: This menu contains the dialogs for configuring the image, event
and recording parameters. Some of these settings can be changed using the
corresponding Quick Controls in the live screen.
Resetting changes:• If you would like to reset some larger changes in one dialog
window without resetting the complete configuration, you can use the Default button
at the bottom of the dialog to reset only this dialog's settings to the factory defaults. If
you would like to reset all image settings, you can do so using the Manage Settings >
Restore Image Settings of the Quick Control in the live image of the camera.
Storing changes permanently:• Once you have finished configuring the camera,
you should always store the settings in the camera's permanent memory. You can
do so in each dialog (clicking the Set button at the bottom of each dialog will tem-
porarily implement the change; when you click Close, you will be asked to store the
complete configuration in the camera's permanent memory) or in the admin menu
(Admin Menu > Store current conguration into ash memory). The Conguration
section of the administration menu provides more functions for storing, copying and
managing camera settings. For more information on this topic, see chapter 5, Basic
Camera Configuration in the Camera Software Manual Part 2 .
Time tasks and time synchronization:• Apart from a multitude of possibilities for
controlling the camera using time (time tables, holiday and vacation, scheduled
tasks, etc.), the camera can also synchronize its internal clock. This allows you to
manually synchronize the camera with a computer or automatically using a time
server or another MOBOTIX camera. The camera can use either NTP time servers or
Time Protocol servers. For additional information, see section 5.4.2, Date and Time/
Time Zones and Time Servers in the Camera Software Manual Part 2 .
The "More" and "Less" buttons:• When opening some of the camera dialogs, the
camera only shows the most important parameters. These dialogs have a More
button in the bottom right corner; click it to display additional options. If all options
are displayed, click the Less button to hide the additional options.
User Name: admin
password: meinsm
Make sure to permanently
store changed parameters!
Automatic time synchroniza-
tion using a time server
More: Display
advanced features
Less: Hide advanced
features
