Installation Guide

6
OUTLINES AND DIMENSIONS
3
R(L) : Refrigerator compartment (Left)
R(R) : Refrigerator compartment (Right)
I : Ice making compartment
S : Select compartment [Versa compartment]
F : Freezer compartment
V : Vegetable compartment
DOOR DIMENSION
Unit: mm
MR-WX743C-A
R(L) R(R) I S F V
Height 865 865 207 207 324 367
Width 284 510 284 510 800 800
7.5
200
7.5
1,722
2,240
1,821
800
352
991
748
738
50
1,216
949
55
192
REQUIRED SPACE FOR INSTALLATION
Distance between the
refrigerator body and
the wall to open the door
to 90 degrees
(Including the
adjustable support cover)
(Pitch between the front wheels)
(Pitch between the adjust bolts)
(Pitch between the rear wheels)
(Including the adjustable support cover)
(Excluding the adjustable support cover)
(Display)
(Display)
(Display)
(Cabinet)
378(Front)/407(Rear)
(Max.)
(Min.)
(Max.)
(Min.)
(Max.)
(Min.)
(Max.)
(Min.)
(Max.)
(Min.)
(Max.)
(Min.)
Bottle pocket (Large)Bottle pocket (Small)
Adjustable Pocket (Large)
Adjustable Pocket (Small)
OAH176A
