MELSOFT

7. SYSTEM CHECKING FROM PERIPHERAL DEVICE

Item Description

PLC Type

Select a connection type between GOT1000 series and the programmable controller when

using the GOT transparent mode.

[For QD75 projects]

This item can be set when "via GOT transparent mode" is selected.

"Direct coupled" or "Bus" can be selected.

When "Serial communication" is set for programmable controller side interface, the

connection type between GOT1000 series and serial communication module is fixed to

"Direct coupled".

[For LD75/LD77 projects]

The connection type between GOT1000 series and the programmable controller is fixed to

"Direct coupled".

I/O adr.

Set the I/O address (start I/O number) of the positioning module to be accessed in

hexadecimal.

Wait time

Set the time-out period until when the positioning module accepts a request from GX

Configurator-QP. When time-out occurs, the operating axes all stop.

Timeout time Set the suspension time of communication judged as a communication error.

Comm. test

Whether the access target CPU module set in the Connection Setup dialog box can be

communicated normally to the positioning module or not is tested. When normal

communication can be made, the types of the positioning module and CPU module are

displayed.
