6 - 13 6 - 13

MELSOFT

6. PROJECT CREATION

[AD75M QD75M/QD75MH]

Data Type Read to GX Configurator-QP

Start bias speed

Section is changed from basic parameter 2 to basic

parameter 1.

Over limit

Under limit

Stop signal

External signal

Zeroing dog

I/O logic

MPG

These are new items and therefore not read.

Default setting.

ACC/DEC time unit selection This is a disused item and therefore read-disabled.

Near path control mode selection

This is a disused item and therefore read-disabled.

(Because near path control mode is fixed)

External command function selection

External start function selection has been changed

to this name.

Servo Off On-time permissible

restart range setting

Permissible restart range has been changed to this

name.

Manual pulse generator input

selection

Parameter

Speed-position function selection

These are new items and therefore read-disabled.

Default setting.

When servo series is "MR-H-B (MR-

H-BN)"

Values of "MR-H-BN" are read.

When servo series is "MR-J-B" 1 Default values of "MR-J2S-B" are read.

When servo series is "MR-J2-B" Values of "MR-J2-B" are read. 2

Servo

parameter

When servo series is "others" Default values of "MR-J2S-B" are read.

SLV axis

This is a new item and therefore read-disabled.

Default setting.

Positioning

data

Positioning comment Not read from SW1

-AD75P.

Block start data

Start block data has been changed to this name.

Because of reduction in number of blocks, block

numbers 5 to 10 are read-disabled.

"Stop" in special start is replaced by "Wait start".

Indirect data This is a disused item and therefore read-disabled.

1: Default values are used for the QD75MH, since parameter contents are different.

Make setting according to the used servo.

2: The default values of the MR-J2S-B are read since the QD75M is incompatible.

Make setting according to the used servo.

3: The MR-J2-B data are read intact. When using them with the MR-J2S-B or MR-J2-Jr, change the

servo series to the "MR-J2S-B/MR-J2-Jr". If additions or extension settings have been made in the

program, check the data of each setting item.

4: After file reading, condition data setting is needed.
