2. SYSTEM CONFIGURATION
(3) About the connection cables
(a) Connection to QCPU or Q corresponding MELSECNET/H
network remote I/O module by QC30R2 (made by Mitsubishi
Electric)
When the baudrate is set to 115.2/57.6kbps, communication cannot be
made unless the peripheral device used is compatible with the
communication speed of 115.2/57.6kbps.
If a communication error occurs, reduce the baudrate setting and restart
communication.
(b) Connection to QCPU/LCPU or C Controller module
(Q12DCCPU-V) by USB cable
• Usable when the USB driver has been installed with any of the following
operating systems used.
Microsoft
R
Windows
R
98 Operating System
Microsoft
R
Windows
R
Millennium Edition Operating System
Microsoft
R
Windows
R
2000 Professional Operating System
Microsoft
R
Windows
R
XP Professional Operating System
Microsoft
R
Windows
R
XP Home Edition Operating System
Microsoft
R
Windows Vista
R
Home Basic Operating System
Microsoft
R
Windows Vista
R
Home Premium Operating System
Microsoft
R
Windows Vista
R
Business Operating System
Microsoft
R
Windows Vista
R
Ultimate Operating System
Microsoft
R
Windows Vista
R
Enterprise Operating System
Microsoft
R
Windows
R
7 Starter Operating System
Microsoft
R
Windows
R
7 Home Premium Operating System
Microsoft
R
Windows
R
7 Professional Operating System
Microsoft
R
Windows
R
7 Ultimate Operating System
Microsoft
R
Windows
R
7 Enterprise Operating System
• Use of the USB cable allows only programmable controller CPU to be
connected.
(c) Connection to QCPU/LCPU by Ethernet cable
• Connect the personal computer with the Built-in Ethernet port QCPU or
LCPU directly by using the Ethernet cable.
The GX Configurator-QP does not support the online connection between
the personal computer and the Built-in Ethernet port QCPU or LCPU.
• Use the following Ethernet cables.
Connection mode Specifications
10BASE-T connection Cables compliant with Ethernet standards, category 3 or higher (STP/UTP cables)
100BASE-TX connection Cables compliant with Ethernet standards, category 5 or higher (STP/UTP cables)
In an environment subject to electric noise, use shielded twisted-pair (STP)
cables.
