11 - 39 11 - 39

MELSOFT

11. USEFUL FUNCTIONS

DISPLAY/SETTING DATA

Item Description

Trigger condition

Choose the actual trace starting condition.

• No condition

Trace starts at the start request of the peripheral device.

• Wait start

Trace actually starts when the start signal (X10/X11/X12/X13) turns on after the start

request from the peripheral device.

Trace stop mode

Choose the trace stopping condition.

• Buffer full

Trace stops when the trace data area becomes full.

• Endless

Trace stops at the stop request of the peripheral device.

• Error stop

Trace stops when an error occurs.

• Trace point

[For QD75P and QD75D projects]

Trace stops when the number of trace points reaches the specified value (1 to 8192).

[For LD75 projects]

Trace stops when the number of trace points reaches the specified value (1 to 16384).

Data 1

Data 2

Represents the trace data No.

Axis selection

Choose the combination of the axes whose data will be traced.

In the locus data of the trace results, the fist axis number is for the horizontal axis and the

latter axis number is for the vertical axis.

When you selected "#1-#4", #1 is for the horizontal axis and #4 for the vertical axis.

Trace data

Choose the data type to be traced.

• Command position

Locus data of the feed address from the QD75P, QD75D and LD75 to the servo amplifier.

"OK" button

Click this button to close the Trace setting dialog box and display the axis numbers and data

types in the Location trace window.
