MELSOFT

11. USEFUL FUNCTIONS

DISPLAY/SETTING DATA

Item Description

Trace interval

[For QD75P and QD75D projects]

Set the trace interval within the range 1 to 256.

The interval is the set value

1.77ms.

[For LD75 projects]

Set the trace interval within the range 1 to 512.

The interval is the set value

0.88ms.

Trigger condition

Choose the actual trace starting condition.

• No condition

Trace starts at the start request of the peripheral device.

• Wait start

Trace actually starts when the start signal (X10/X11/X12/X13) turns on after the start

request from the peripheral device.

Trace stop mode

Choose the trace stopping condition.

• Buffer full

Trace stops when the trace data area becomes full.

• Endless

Trace stops at the stop request of the peripheral device.

• Error stop

Trace stops when an error occurs.

• Trace point

[For QD75P and QD75D projects]

Trace stops when the number of trace points reaches the specified value (1 to 8192).

[For LD75 projects]

Trace stops when the number of trace points reaches the specified value (1 to 16384).

Data 1

Data 2

Data 3

Data 4

Represents the trace data No.

Axis selection Choose the axis whose data will be traced.

Trace data

Choose the data type to be traced.

• Command speed

Waveform data of the feed speed from the QD75P, QD75D and LD75 to the servo

amplifier.

"OK" button

Click this button to close the Trace setting dialog box and display the axis number and data

type in the wave trace window.
