9 - 6 9 - 6

MELSOFT

9. WRITING TO/READING OF/VERIFICATION OF POSITIONING

MODULE DATA

9.2 Servo Amplifier Data Read

PURPOS

Read the servo parameters used in the servo amplifiers to the QD75M buffer

memory.

(Note that they cannot be read in QD75P/QD75D/QD75MH/LD75/LD77 projects.)

The servo parameters read to the QD75M buffer memory are not written to the flash

ROM. To write them to the flash ROM, write them to the flash ROM separately.

BASIC OPERATIO

1. Place the QCPU in the STOP status.

When performing servo amplifier data read without putting the QCPU in the

STOP status, change the PLC state check setting in Option setting.

2. On the project tree view, set the required project as an active project. (Refer to

Section 5.2.)

3. Click the [Online]

[Servo amplifier data read] menu.

4. Click the "Action" button in the servo amplifier data read dialog box.
