8 - 5 8 - 5

MELSOFT

8. DATA SETTING

The parameter setting items and setting values of QD75M have been added to GX

Configurator-QP Version 2.13P or later. (Refer to Appendix 3)

The following table indicates operations that will be performed if the project created on

GX Configurator-QP Version 2.13P or later is opened on GX Configurator-QP Version

2.12N or earlier.

Type Item Setting (Set Value)

Operation Performed when Project

Is Opened using GX Configurator-

QP earlier than Version 2.12N

Action

For version 2.13P to 2.17T,

"B: MR-RB31", "C: MR-RB51"

Servo parameter

(for MR-J2S-B)

Regenerative

brake option

For version 2.18U or later,

"00: Not used"

"01: FR-RC, FR-BU"

"05: MR-RB32", "06: MR-RB34"

"07: MR-RB54", "08: MR-RB30"

"09: MR-RB50", "0B: MR-RB31"

"0C: MR-RB51", "0E: Standard + fan"

"10: MR-RB032", "11: MR-RB12"

"12: MR-RB14", "13: MR-RB5E"

"14: MR-RB5E + fan", "15: MR-RB67"

"16: MR-RB67 + fan", "17: MR-RB9F"

"18: MR-RB9F + fan", "80: MR-RB3H-4"

"81: MR-RB5H-4", "82: MR-RB3G-4"

"83: MR-RB5G-4", "84: MR-RB34-4"

"85: MR-RB54-4", "86: MR-RB1L-4"

"87: MR-RB3L-4"

• Cell (table) is shown red (outside

the setting range).

• Error check results in error.

Since the setting is

retained, it can be

saved or written as-is.

Servo parameter

(for MR-J2S-B)

Zeroing

condition

setting

selection

"0: It is necessary to pass through one Z-

phase after power on."

"1: There is no need to pass through one

Z- phase after power on."

Not displayed

Since the setting is

retained, it can be

saved or written as-is.

The defaults (initial values) are displayed if the project created using GX Configurator-

QP earlier than Version 2.12N is opened using GX Configurator-QP Version 2.13P or

later.
