5.1.25 REAL_TO_STR(_E)
Outline
This function converts float (single precision) data into string data, and outputs the data obtained by
conversion.
1. Format
*1. Output variable
2. Set data
In explanation of functions, I/O variables inside ( ) are described.
Explanation of function and operation
1) This function converts float (single precision) data stored in a device specified in into string
(exponent) data, and outputs the data obtained by conversion to a device specified in .
FX3U(C) FX3G FX2N(C) FX1N(C) FX1S FX U /FX 2C FX0N FX0(S)
Function name
Expression in each language
Structured ladder ST
REAL_TO_STR
REAL_TO_STR(_REAL);
Example:
Label 2:=
REAL_TO_STR(Label 1);
REAL_TO_STR_E
REAL_TO_STR_E(EN,_REAL,
Output label);
Example:
REAL_TO_STR_E(X000, Label 1,
Label 2);
Variable Description Data type
Input
variable
EN Execution condition Bit
_REAL ( )
Conversion source float (single precision) data FLOAT (Single Precision)
Output
variable
ENO Execution status Bit
*1 ( )
String data after conversion String
REAL_TO_STR
_REAL *1
Label 2Label 1
REAL_TO_STR_E
EN ENO
*1
Label 2
X000
Label 1
_REAL
s
d
s
d
Float
(single
precision)
data
ASCII code
for integer part
ASCII code
for 1st decimal place
ASCII code (2EH)
for decimal point (.)
ASCII code
for 2nd decimal place
ASCII code
for 4th decimal place
45H(E)
20H (space)
ASCII code for tens
place of exponent part
ASCII code
for 3rd decimal place
ASCII code
for 5th decimal place
ASCII code for ones
place of exponent part
High-order byte
Sign data (integer part)
Sign data
(exponent part)
Low-order byte
00H
Automatically stored at the end of the character string
String
1st word
2nd word
3rd word
4th word
5th word
6th word
7th word
E
Sign (exponent part)Sign
(integer part)
Added
automatically
.
