Appendix A: Correspondence between Devices and
Addresses
The table below shows the correspondence between devices and addresses.
Device
Notation
Example of correspondence between device
and address
Device Address Device Address
Input relay X Xn %IXn X367 %IX247
Output relay Y Yn %QXn Y367 %QX247
Auxiliary relay M Mn %MX0.n M499 %MX0.499
Timer
Contact TS Tn %MX3.n TS191 %MX3.191
Coil TC Tn %MX5.n TC191 %MX5.191
Current value TN Tn
%MW3.n
%MD3.n
TN190
T190
%MW3.191
%MD3.190
Counter
Contact CS Cn %MX4.n CS99 %MX4.99
Coil CC Cn %MX6.n CC99 %MX6.99
Current value CN Cn
%MW4.n
%MD4.n
CN98
C98
%MW4.99
%MD4.98
Data register D Dn
%MW0.n
%MD0.n
D198*
D198
%MW0.199
%MD0.198
Intelligent function unit
device
GUx\Gn
%MW14.x.n
%MD14.x.n
U0\G09
U0\G09
%MW14.0.10
%MD14.0.9
Extension register R Rn
%MW2.n
%MD2.n
R32766
R32766
%MW2.32767
%MD2.32766
Extension file register ER ERn No correspondence - -
Pointer P Pn " "(NULL character) P4095 No correspondence
Interrupt pointer I In No correspondence - -
Nesting N Nn No correspondence - -
Index register
ZZn
%MW7.n
%MD7.n
Z6
Z6
%MW7.7
%MD7.6
V Vn %MW6.n V7 %MW6.7
State S Sn %MX2.n S4095 %MX2.4095
