5.9 Functions Of Time Data Types
198
FXCPU Structured Programming Manual
(Application Functions)
5.9 Functions Of Time Data Types
5.9.1 ADD_TIME(_E)
Outline
This function adds time data.
1. Format
*1. Output variable
2. Set data
In explanation of functions, I/O variables inside ( ) are described.
Explanation of function and operation
This function performs addition ( + ) of time data stored in devices specified in and , and
outputs the operation result expressed as time data to devices specified in .
FX3U(C) FX3G FX2N(C) FX1N(C) FX1S
FX
U
/FX
2C
FX0N FX0(S)
Function name
Expression in each language
Structured ladder ST
ADD_TIME
ADD_TIME(_IN1,_IN2);
Example:
Label 3:=
ADD_TIME(Label 1,Label 2);
ADD_TIME_E
ADD_TIME_E(EN,_IN1,_IN2,
Output label);
Example:
ADD_TIME_E(X000,Label 1,
Label 2,Label 3);
Variable Description Data type
Input
variable
EN Execution condition Bit
_IN1 ( )
Head word device which stores time data to get addition Time
_IN2 ( )
Head word device which stores addition time data Time
Output
variable
ENO Execution status Bit
*1 ( )
Head word device which will store the operation result Time
ADD_TIME
*1
Label 3Label 1 _IN1
Label 2
_IN2
ADD_TIME_E
EN ENO
*1
Label 3
X000
Label 1
_IN1
Label 2
_IN2
s1
s2
d
s1
s2
s1
s2
d
