12
FXCPU Structured Programming Manual
(Application Functions)
FX
0/FX0S/FX0N/FXU/FX2C PLCs [whose production is finished]
Manuals of models whose production is finished
Production is finished for FX
0/FX0S/FX0N/FXU/FX2C PLCs.
Manual name Manual number
Supplied with product
or Additional Manual
Contents
Model
name code
PLC main unit
FX0/FX0N HARDWARE MANUAL JY992D47501 Supplied with product
Details about the hardware including I/O
specifications, wiring, installation and
maintenance of the FX0/FX0N PLC main unit.
-
FX0S HARDWARE MANUAL JY992D55301 Supplied with product
Details about the hardware including I/O
specifications, wiring, installation and
maintenance of the FX0S PLC main unit.
-
FX/FX2C HARDWARE MANUAL JY992D47401 Supplied with product
Details about the hardware including I/O
specifications, wiring, installation and
maintenance of the FXU/FX2C PLC main unit.
-
Programming
FX Series User's Manual -Data
Communication Edition
JY997D16901 Additional Manual
Details about simple N : N link, parallel link,
computer link and no-protocol communication
(RS instruction and FX2N-232IF).
09R715
