Inputs 5.
5-1
1
2
3
4
5
6
7
8
5. Inputs
5.1 24V DC input Specifications
FX
1N
main unit,
extension block
FX
0N
, FX
2N
Extension block
X0
→
X7 X10
→
∞
Input voltage 24V DC
±
10%
Input current 24V DC, 7mA 24V DC, 5mA 24V DC, 5mA
Input switching
current
OFF
→
ON >4.5mA >3.5mA >3.5mA
ON
→
OFF <1.5mA
Response time 10ms
Variable response time X000-X007 0-15ms ---
Circuit isolation Photocoupler
Operation indication LED is lit
FX1N Series Programmable Controllers
