FX1N Series Programmable Controllers Diagnostics 7.
7-5
1
2
3
4
5
6
7
8
7.6
PLC Status Registers
02H=EEPROM protect switch OFF
0AH=EEPROM protect switch ON
10H=MPU memory
D8000
(default 200ms)
D8001
D8002
D8003
D8004
W atchdog timer
PLC version
26100 = FX
1N
Version 1.00
26 = FX
1N
, 100 = Version 1.00
Memory capacity
0008=8K steps
Memory type
Error flag number
8060=M8060, (8060-8068)
