E-33
General Operation
Controlling the Projector from a Computer
Use the control connector if the projector cannot be operated with the remote control unit, for example when it is
suspended from the ceiling.
Connecting the computer and projector
Use a commercially available serial cable (D-Sub 9-pin, straight) to connect the computer’s RS-232C connector to the projector’s
control connector (PC CONTROL).
Serial cable (D-Sub 9-pin, straight) (commercially available)
RS-232C
connector
Note:
* This function may not work with some computers.
* Specialized knowledge is required to use the control connector. Consult a specialist, such as the person suspending the projector from the
ceiling.
