# Items Details
Setting range (unit)
1286
(PR)
ext22 Not used.
1287
(PR)
ext23
(bit0)
Workpiece
coordinate
display
Select the mode of displaying the workpiece coordinate
counter.
0: Does not update the display immediately after
workpiece coordinate data is changed.
1: Updates the display immediately after workpiece
coordinate data is changed.
0/1
ext23
(bit4)
Relative
coordinate
display
(M system)
0: Displays the actual position including tool length
compensation.
1: Displays the machining position in terms of a
program command excluding tool length compen-
sation.
(L system)
0: Displays the actual position including tool shape
compensation.
1: Displays the machining position in terms of a
program command excluding tool shape compen-
sation.
0/1
ext23
(bit5)
Relative
coordinate
display
(M system)
0: Displays the actual position including tool radius
compensation.
1: Displays the machining position in terms of a
program command excluding tool radius compen-
sation.
(L system)
0: Displays the actual position including nose R
compensation.
1: Displays the machining position in terms of a
program command excluding nose R compen-
sation.
0/1
ext23
(bit6)
Absolute
coordinate
display
(M system)
0: Displays the actual position including tool length
compensation.
1: Displays the machining position in terms of a
program command excluding tool length compen-
sation.
(L system)
0: Displays the actual position including tool shape
compensation.
1: Displays the machining position in terms of a
program command excluding tool shape compen-
sation.
0/1
