User manual

8. Spindle Parameters
8.3 MDS-B-SP/SPH, MDS-C1-SP/SPH
232
No. Items Details
Setting
range
Standard
setting
3453 SP253 DA1NO D/A output
channel 1
data
number
Set the output data number for channel 1
of the D/A output function.
When set to "0", the output is
speedometer.
Refer to "9.4 (1) For D/A output
functions".
–32768 to
32767
0
3454 SP254 DA2NO D/A output
channel 2
data
number
Set the output data number for channel 2
of the D/A output function.
When set to "0", the output is load meter.
Refer to "9.4 (1) For D/A output
functions".
–32768 to
32767
0
3455 SP255 DA1MPY DA output
channel 1
magnifica-
tion
Set the data magnification for channel 1
of the D/A output function.
The output magnification is the setting
value divided by 256.
When set to "0", the output magnification
becomes 1-fold, in the same manner as
when "256" is set.
Refer to "9.4 (1) For D/A output
functions".
–32768 to
32767
(1/256-fold)
0
3456 SP256 DA2MPY DA output
channel 2
magnifica-
tion
Set the data magnification for channel 2
of the D/A output function.
The output magnification is the setting
value divided by 256.
When set to "0", the output magnification
becomes 1-fold, in the same manner as
when "256" is set.
Refer to "9.4 (1) For D/A output
functions".
–32768 to
32767
(1/256-fold)
0
