8. Spindle Parameters
8.2 MDS-B-SPJ2
190
No. Items Details
Setting
range
Standard
setting
3276 SP076
Not used. Set to “0”.
0 0
3277 SP077 TDSL Fixed control
constant
Set by Mitsubishi.
Set "0" unless designated in particular.
0 0
3278
(PR)
SP078 FPWM
3279
(PR)
SP079 ILMT
3280 SP080
3281 SP081 LMCA
3282 SP082 LMCB
3283
to
3286
SP083
to
SP086
Not used. Set to "0".
0 0
3287
(PR)
SP087 DIQM Target value
of variable
torque limit
magnification
at
deceleration
Set the minimum value of variable torque limit
at deceleration.
0 to 150
(%)
75
3288
(PR)
SP088 DIQN Speed for
starting
change of
variable
torque limit
magnifica-
tion at
deceleration
Set the speed for starting change of torque
limit value at deceleration.
SP088 SP017
100%
SP087
Speed
Inversely proportional
to speed
Torque limit
0 to 32767
(r/min)
3000
3289
to
3292
SP089
to
SP092
Not used. Set to "0". 0 0
3293
(PR)
SP093 ORE Fixed control
constant
Set by Mitsubishi.
Set "0" unless designated in particular.
0 0
3294
(PR)
SP094
Not used. Set to “0”.
0 0
3295
(PR)
SP095 VFAV Fixed control
constant
Set by Mitsubishi.
Set "0" unless designated in particular.
0 0
