8. Spindle Parameters
8.1 Spindle Base Specifications Parameters
179
# Items Details
Setting range
(Unit)
3060 sptc7 Spindle
synchroniza-
tion multi-step
acceleration/
deceleration
changeover
speed 7
Set the spindle speed for changing the 7th step's
acceleration/deceleration time constant.
0 to 99999 (r/min)
3061 spdiv1 Magnification
for time
constant
changeover
speed 1
Set the acceleration/deceleration time constant
between the spindle synchronization multi-step
acceleration/deceleration changeover speed 1
(sptc1) to the spindle synchronization multi-step
acceleration/deceleration changeover speed 2
(sptc2) as a magnification in respect to the
spindle synchronization
acceleration/deceleration time constant (spt).
0 to 127
3062 spdiv2 Magnification
for time
constant
changeover
speed 2
Set the acceleration/deceleration time constant
between the spindle synchronization multi-step
acceleration/deceleration changeover speed 2
(sptc2) to the spindle synchronization multi-step
acceleration/deceleration changeover speed 3
(sptc3) as a magnification in respect to the
spindle synchronization
acceleration/deceleration time constant (spt).
0 to 127
3063 spdiv3 Magnification
for time
constant
changeover
speed 3
Set the acceleration/deceleration time constant
between the spindle synchronization multi-step
acceleration/deceleration changeover speed 3
(sptc3) to the spindle synchronization multi-step
acceleration/deceleration changeover speed 4
(sptc4) as a magnification in respect to the
spindle synchronization
acceleration/deceleration time constant (spt).
0 to 127
3064 spdiv4 Magnification
for time
constant
changeover
speed 4
Set the acceleration/deceleration time constant
between the spindle synchronization multi-step
acceleration/deceleration changeover speed 4
(sptc4) to the spindle synchronization multi-step
acceleration/deceleration changeover speed 5
(sptc5) as a magnification in respect to the
spindle synchronization
acceleration/deceleration time constant (spt).
0 to 127
3065 spdiv5 Magnification
for time
constant
changeover
speed 5
Set the acceleration/deceleration time constant
between the spindle synchronization multi-step
acceleration/deceleration changeover speed 5
(sptc5) to the spindle synchronization multi-step
acceleration/deceleration changeover speed 6
(sptc6) as a magnification in respect to the
spindle synchronization
acceleration/deceleration time constant (spt).
0 to 127
