HT60D / HT70S Hedgetrimmer

41

Original Instructions Version Mar12

ID PART NUMBER DESCRIPTION QTY

31 MIGJB25D.00.00-5 FUEL TANK ABSORBER 2

32 MITBC431D.01.13.01-2 STOPPER 1

33 MITBC431D.01.13.01 FUEL CAP ASSY 1

35 MIGJB25D.00.00-7 WASHER 1

36 MIYD45.03.03-00 FUEL FILTER 1

37 MIGJB25D-2.03.00-2 FUEL PIPE 1

38 MIGJB25D-2.03.00-3 RETURN PIPE 1

39 MITBC431D.01.13.00-6 FUEL PIPE 2.5×5×95 1

40 MITBC431D.01.13.00-3 GROMMET 1

41 MIYD38-3.00.00-17 OIL PIPE CIRCLIP 1

42 MIYD38-3.03.06-00 BREATHER ASSEMBLY 1

43 MIYD62.02.00-3 STARTER HANDLE 1

44 MIGJB25D.02.00-3 ROPE 1

45 MIYD25.02.01-2 ROPE GUIDE 1

46 MITHT245D.02.01 RECOIL STARTER ASSY 1

47 MITBC261D.01.12.00-5 RECOIL SPRING 1

48 MITBC261D.01.12.00-4 RECOIL PULLEY 1

49 MITHT245D.02.01-2 TORSION SPRING 1

50 MITHT245D.02.01-3 RATCHET GEAR 1

51 MIGB/T9074.19

ST4.8X10

SCREW ST4.8×10 1

52 MIGB/T818 M5X16 SCREW 4

53 MITHT245D.02.00-4 TOP COVER 1

54 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 1

55 MIGJB25D.00.01-00 CORD SPLINT 1

56 MIGJB25D-2.02.00-5 FRONT COVER 1

57 MIGJB25D-2.05.02-1 CABLE HOLDER 1

58 MIGB/T845 M4X14 SCREW M4×14 1

59 MIGJB25S.05.00-0A THROTTLE TRIGGER ASSY 1

HT70S

Parts - Main Body
