HT70S Parts - Main Body
ID PART NUMBER DESCRIPTION QTY
1 MIGJB25D-2.00.00-3 MUFFLER COVER 1
2 MIGB/T818 M5X12 SCREW M5X12 1
3 MIGB/T845 ST4.2X14 TAPPING SCREW ST4.2X14 10
4 MIGJB25S.00.00-15 HANDLE LOWER BRACKET 1
5 MIGJB25S.00.00-17 SPACER SLEAVE 2
6 MIGJB25S.00.00-16 HANDLE UPPER BLOCK 4
7 MIGB/T70.1 M5X45 SCREW M5X45 2
8 MIGB/T93 M5 SPRING WASHER M5 4
9 MIGJB25S.00.00-18 WASHER 2
10 MIGB/T6186 M5 NUT M5 3
11 MIGJB25S.05.00-8 BOTTOM PACKING 1
12 MIGB/T70.1 M5X35 SCREW M5X35 2
13 MIGB/T96 M5 WASHER M5 3
14 MIGJB25S.05.00-7 REAR HANDLE 1
15 MIYD38-3.01.11.04-00 ON/OFF SWITCH 1
17 MIGJB25S.05.00-3 TRIGGER 1
18 MIGJB25S.05.00-5 TRIGGER LOCK 1
19 MIGJB25S.05.00-4 TRIGGER SPRING 1
20 MIGJB25S.05.00-6 TRIGGER LOCK SPRING 1
22 MIGB/T818 M5X30 SCREW M5X30 1
23 MIGJB25S-2.05.02-00 THROTTLE CABLE 1
24 MIGJB25S.05.01-00 GROUNDING WIRE B 1
25 MIGJB25S.05.03-00 GROUNDING WIRE C 1
26 MIGJB25S.00.00-19 CABLE TIE 3X100 1
27 MIGJB25S.05.00-9 LEAD BUSHING 1
28 MIGB/T818 M5X25 SCREW M5X20 1
29 MIGJB25D.00.00-6 FUEL TANK BUSH 1
30 MIGJB25D.03.00-4 FUEL TANK 1
