HT60D / HT70S Hedgetrimmer

35

Original Instructions Version Mar12

ID PART NUMBER DESCRIPTION QTY

31 MIYD25.01.00.00-2 IGNITION GASKET 2

32 MIYD25.01.03.00-3 NEEDLE BEARING WASHER 2

33 MIYD25.01.03.05-00 NEEDLE BEARING 8X11X9 1

34 MIYD36.01.03.00-4 CIRCLIPS 2

35 MIGJB25D.01.03.02-00 PISTON 1

36 MIGJB25D.01.03.00-2 PISTON PIN 1

37 MIGJB25D.01.03.00-1 PISTON RING 2

38 MIGJB25D.01.00.01-00 CYLINDER GASKET 1

39 MIGB/T70.1 M5X55 CAP SCREW M5X55 2

40 MIGJB25S.01.09.01-00 MUFFLER 1

41 MIGJB25D.01.00.00-9 MUFFLER GASKET 2

42 MIGJB25D.01.00.00-2 GUIDE FLOW PLATE 1

43 MISPBPRM7A SPARK PLUG - NGK BPMR7A 1

44 MIGJB25D.01.00.00-3 CYLINDER 1

45 MIGJB25D.01.00.00-5 GASKET 1

46 MIGB/T6175 M5 NUT M5 2

47 MIGJB25D-2.01.00.07-00 MANIFOLD 1

48 MIGB/T70.1 M5X20 BOLT M5X20 2

49 MIGJB25D.01.11.00-1 SPARK PLUG COVER 1

50 MIGJB25D.01.00.00-1 CYLINDER COVER 1

51 MIGJB25D-2.01.00.00-6 CARBURETOR GASKET 1

52 MIGJB25D-2.01.06.00-00 CARBURETOR 1

53 MIGJB25D-2.01.08.01-3 AIR FILTER BASE 1

54 MIGB/T9074.4 M5X60 SCREW M5X60 2

55 MIGJB25D-2.01.08.00-2 AIR FILTER 1

56 MIGJB25D-2.01.08.00-1 AIR FILTER COVER 1

57 MICGSHT60/70 CARB GASKET KIT 1

58 MIGJB25D.01.00.00 CLUTCH ASSY 1

HT70S

Parts - Engine Unit
