Operator`s manual

HT60D / HT70S Hedgetrimmer
32
Original Instructions Version Mar12
ID PART NUMBER DESCRIPTION QTY
31 MITBC431D.01.13.01 FUEL CAP ASSY 1
32 MIYD45.03.03-00 FUEL FILTER 1
33 MITBC431D.01.13.00-3 FUEL GROMMET 1
34 MITBC431D.01.13.00-6 FUEL PIPE 2.5×5×95 1
35 MIGJB25D-2.03.00-2 FUEL PIPE 1
36 MIGJB25D-2.03.00-3 RETURN PIPE 1
37 MIGJB25D.00.01-00 CORD SPLINT 1
38 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 1
39 MIYD38-3.03.06-00 BREATHER ASSEMBLY 1
40 MIYD38-3.00.00-17 OIL PIPE CIRCLIP 1
41 MIYD38-5.02.00-4 RECOIL HANDLE 1
42 MIGJB25D.02.00-3 ROPE 1
43 MIYD25.02.01-2 ROPE GUIDE 1
44 MITHT245D.02.01 RECOIL STARTER ASSY 1
45 MITBC261D.01.12.00-5 RECOIL SPRING 1
46 MITBC261D.01.12.00-4 RECOIL PULLEY 1
47 MITHT245D.02.01-2 TORSION SPRING 1
48 MITHT245D.02.01-3 RATCHET GEAR 1
49 MIGB/T9074.19
ST4.8X10
SCREW ST4.8×10 1
50 MITHT245D.02.00-4 TOP COVER 1
51 MIGB/T818 M5X16 SCREW 4
52 MIGJB25D-2.02.00-5 FRONT COVER 1
53 MIGJB25D.05.01-00 GROUNDING WIRE B 1
54 MIGJB25D-2.05.02-00 THROTTLE CABLE 1
55 MIGJB25D-2.05.02-1 CABLE HOLDER 1
56 MIGB/T845 M4X14 SCREW M4×14 1
HT60D Parts - Main Body
