HT60D Parts - Main Body
ID PART NUMBER DESCRIPTION QTY
1 MIGJB25D.00.00-8 FRONT HANDLE 1
2 MIGB/T845 ST4.8X25 TAPPING SCREW ST4.8X25 2
3 MIGJB25D-2.00.00-3 MUFFLER COVER 1
4 MIGJB25D.00.00-10 FRONT ABSORBER SPRING 2
5 MIGB/T96 M5 WASHER M5 5
6 MIGB/T93 M5 SPRING WASHER M5 4
7 MIGB/T70.1 M5X14 CAP HEAD SCREW M5X14 4
8 MIGJB25D.00.00-9 BASE 1
9 MIGJB25D.00.00-11 REAR ABSORBER SPRING 2
10 MIGJB25D.00.00-12 SPRING BLOCK 2
11 MIGB/T845 ST4.2X14 TAPPING SCREW ST4.2X14 16
12 MIGJB25D.00.00-1 WIRE COVER 1
13 MIGJB25D.05.00-7 LOCK KNOB 1
14 MIGJB25D.05.00-00A REAR HANDLE ASSY (PRO SERIES) 1
15 MIGJB25D.05.00-8 RETURN SPRING 1
16 MIGJB25D.05.00-6 LOCK LEVER 1
17 MIGJB25D.05.00-5 TRIGGER LOCK 1
18 MIGJB25D.05.00-4 TRIGGER TORSION ROD SPRING 1
19 MIGJB25D.05.00-3 THROTTLE TRIGGER 1
21 MIYD38-3.01.11.04-00 ON/OFF SWITCH 1
22 MIGJB25D.00.00-2 HANDLE LOCK 1
23 MIGB/T818 M5X12 SCREW M5X12 2
24 MIGJB25D.00.00-7 WASHER 1
25 MIGJB25D.00.00-6 FUEL TANK BUSH 1
26 MIGB/T818 M5X25 SCREW M5X20 1
27 MIGJB25D.03.00-4 FUEL TANK 1
28 MIGJB25D.00.00-5 FUEL TANK ABSORBER 2
29 MITBC431D.01.13.01-2 STOPPER 1
