HT60D Parts - Blade Drive
ID PART NUMBER DESCRIPTION QTY
1 MIGJB25D.04.00-8 CLUTCH DRUM 1
2 MIGB/T97.1 M5 WASHER M5 15
3 MIGB/T93 M5 SPRING WASHER M5 15
4 MIGB/T818 M5X12 SCREW M5X12 2
5 MIGJB25D.04.00-4 GEAR CASE 1
6 MIGB/T97.1 M6 FLAT WASHER M6 4
7 MIGB/T93 M6 LOCK WASHER M6 3
8 MIGB/T70.1 M6X22 SCREW M6X22 3
9 MIGJB25D.04.00-9 GEAR CASE GASKET 1
10 MIGJB25D.04.00-6 LINK ROD PLATE 2
11 MIGJB25D.04.01-00 GREASE NIPPLE 1
12 MIGB/T276 6001-2Z BEARING 6001-2Z 12X28X8 2
13 MIGB/T818 M4X10 SCREW M4X10 4
14 MIGB/T893.1 28 CIRCLIPS SIZE 28 1
15 MIGJB25D.04.00-10 GEAR SHAFT 1
16 MIGB/T276 61805-2Z BEARING 61805-2Z 25X37X7 2
17 MIGJB25D.04.00-7 ECCENTRIC GEAR 1
18 MIGJB25D.04.00-11 CON ROD 2
19 MIGB/T119.2 6X35 PIN 6X35 1
20 MIGB/T119.2 3X9 PIN 3X9 2
21 MIGJB25D.04.00-5 GEAR CASE COVER 1
22 MIGB/T70.1 M5X18 CAP HEAD SCREW M5X18 9
23 MIGJB25D.04.00-1 FELT SEAL 1
24 MIGB/T70.1 M5X30 CAP HEAD SCREW M5X30 2
25 MIGJB25D.04.00-2 RECTANGULAR PLATE 1
26 MIGB/T70.1 M5X22 CAP HEAD SCREW M5X22 1
27 MIGB/T70.1 M5X20 BOLT M5X20 2
28 MIGJB25D.06.00-2 BOTTOM PLATE 1
