HT60D Parts - Engine Unit
ID PART NUMBER DESCRIPTION QTY
1 MIGB/T6187.1 M6 HEXAGON NUT WITH FLANGE M6 1
2 MIGB/T70.2 M6X16 PAN HEAD SCREW M6X16 2
3 MIGJB25D.01.00.03 STARTER RATCHET ASSY 2
6 MIGB/T896 4 E-RING SIZE 4 2
7 MIGJB25D.01.10.00-00 FLYWHEEL 1
8 MIGB/T70.1 M5X25 CAP HEAD SCREW M5X25 5
9 MIGB/T93 M5 SPRING WASHER M5 9
10 MIGB/T97.1 M5 WASHER M5 9
11 MIGJB25D.01.00.05-00 OIL SEALS 10X26X5 1
12 MIGB/T893.1 26 E CLIP (SIZE 26) 1
13 MIGJB25D.01.01.00-1 TOP CRANKCASE 1
14 MIGB/T276 6000D BEARING 6000 10X26X8 2
15 MIGJB25D.01.03.01-00 CRANKSHAFT 1
16 MIGB/T119.2 3X9 PIN 3X9 3
17 MIGJB25D.01.01.00-3 CRANKCASE GASKET 1
18 MIGJB25D.01.01.00-2 BOTTOM CRANKCASE 1
19 MIGJB25D.01.00.06-00 OIL SEALS 10X20X5 1
20 MIGJB25D.01.00.00-11 WASHER 1
21 MIGJB25D.01.00.00 CLUTCH ASSY 1
22 MIGJB25D.01.00.00-16 WAVE SPRING WASHER 2
24 MIGJB25D.01.00.00-13 CLUTCH SPRING 1
25 MIGJB25D.01.00.00-14 BOLT FOR CLUTCH 2
26 MIGJB25D.01.11.02-00 GROUNDING WIRE A 1
27 MIGB/T70.1 M4X20 CAP HEAD SCREW M4X20 2
28 MIGB/T97.1 M4 PLAIN WASHER M4 2
29 MIGB/T93 M4 WASHER M4 2
30 MIGJB25D.01.11.01-00 IGNITION COIL 1
31 MIYD25.01.00.00-2 IGNITION GASKET 2
