HT60D / HT70S Hedgetrimmer Component Location 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. Front handle Fuel tank Starter Rear handle Throttle lever Ignition switch Throttle cable Muffler Blade Plate receiver Blade guard PRODUCT DESCRIPTION This Hedge Trimmer is a 2 stroke fast running power tool and is designed to be used in a domestic application for trimming new growth on hedges.
HT60D / HT70S Hedgetrimmer Warnings in the Manual This mark indicates instructions which must be followed in order to prevent accidents which could lead to serious bodily injury or death. ! IMPORTANT This mark indicates instructions which must be followed or it leads to mechanical failure, breakdown, or damage. NOTE This mark indicates hints or useful directions in the use of the product. Safety Symbols (1) Read operator’s instruction book before operating this machine.
HT60D / HT70S Hedgetrimmer (5) Directive 2000-14/CE. Guaranteed noise levels. (6) Danger: risk of exhaust fumes intoxication. Taking Care of Warning Labels Always keep warning labels clean and free of scratches, which might make them illegible or difficult to read. If the warning labels provided with your hedge trimmer become damaged, peel off, or otherwise become illegible or difficult to read, order new labels from the authorised servicing dealer and replace the damaged labels.
HT60D / HT70S Hedgetrimmer Safety Precautions Introduction Read this Owner/Operator Manual carefully. Be sure you understand how to operate this hedge trimmer properly before you use it. Failure to do so could result in serious injury. Keep this manual handy so that you may refer to it later whenever any questions arise. Also note that you are able to contact the dealer from whom you purchased the product for assistance.
HT60D / HT70S Hedgetrimmer Never use the Hedge Trimmer in conditions as described below: When the ground is slippery or when other conditions exist which might make it difficult to maintain a steady posture while using the hedge trimmer. At night, at times of heavy fog, or at any other times when your field of vision is limited and it would be difficult to gain a clear view of the area where the hedge trimmer is to be used.
HT60D / HT70S Hedgetrimmer Never hold the hedge trimmer in a way in which the blades are pointing towards someone else. Never allow the blades to come into contact with your body. Always turn off the engine before adjusting the hedge trimmer, removing branches which have become stuck in the blades, or at any other time when coming into close proximity with the blades. Always wear thick work gloves when adjusting the hedge trimmer. Always place the blade cover provided over the blades when not in use.
HT60D / HT70S Hedgetrimmer Before Operating the Hedge Trimmer Before beginning work, carefully check the work area and remove any obstacles. Within a perimeter of 15 metres of the work area should be considered a hazardous area into which no-one should enter while the hedge trimmer is being used, and when necessary this area should be marked with a warning rope, warning signs, or other forms of warning.
HT60D / HT70S Hedgetrimmer Avoid Noise Problems Check and follow the local regulations for sound levels and hours of operation for garden machinery. In general, operate hedge trimmers between 8 am, and 5 pm on week days and 9 am to 5 pm at weekends. Avoid using the hedge trimmer late at night and/or early in the morning.
HT60D / HT70S Hedgetrimmer Two-Stroke Fuel Fuel is very flammable. Do not smoke or bring any flame or sparks near fuel. Always stop the engine and allow it cool before refuelling. Refuel outdoors on bare ground, restart the engine at least 5m away from the refuelling stop. The engine is lubricated by oil mixed into petrol. Prepare a mixture of unleaded petrol and semi-synthetic two-stroke oil that meets the specifications of: API TC, ISO-L-EGC, JASO FC (Low Smoke) oil. Recommended mixing ratio is 40:1.
HT60D / HT70S Hedgetrimmer Fuel Storage Mixed two-stroke fuel which has been left unused for a period of one month or more may damage the carburettor and result in the engine failing to start or operate correctly. When storing the hedge trimmer for a period of more than one month, empty the fuel tank, and run the engine to empty the carburettor of fuel. Two stroke fuel can cause deterioration of rubber and/or plastic components during prolonged storage.
HT60D / HT70S Hedgetrimmer Operation Keep clear of the blades as they may start moving when engine starts. Starting the Engine CAUTION do not pull the starter cord all the way out and do not let go of the starter handle when the cord is extended, this can damage the starter mechanism. Cold Engine Starting Rest the unit on a flat, firm surface. Keep the blades off the ground and clear of surrounding objects as they may start moving upon starting of the engine.
HT60D / HT70S Hedgetrimmer While holding the unit firmly, pull out the starter rope firmly until engine fires (indicated by a cough from the engine). Move the choke lever (a) to the open position (c) Fig 2. Pull the starter rope until the engine starts. Allow the engine to warm up before use. When cutting, always use the hedge trimmer on full throttle. Hot Engine Starting Set the ignition switch (b) to the start position “I” (d) Fig 3. Pull the starter rope until the engine starts.
HT60D / HT70S Hedgetrimmer Stopping the Engine Set the engine to idling by releasing the throttle lever. Set the ignition switch to the off position ‘’O’’ (STOP). If the engine fails to stop, set the choke lever to the closed position to stall the engine; do not use the machine until the ignition switch is repaired.
HT60D / HT70S Hedgetrimmer Transportation Never transport the hedge trimmer with the engine running. An engine that is running could be accidently accelerated causing the blade to engage. Make sure the blade safety guards are in place when transporting the hedge trimmer. When carrying by hand, the cutting head should be pointing backwards. Ensure the Hedge Trimmer is secure when transporting in a vehicle and the tank is drained of fuel.
HT60D / HT70S Hedgetrimmer HORIZONTAL CUT: In order to get the best cutting results, slightly tilt the blade 5 to 10° towards the cutting direction. Cut slowly, especially when cutting thick hedges. The hedge trimmer must only be used to trim hedges or small bushes. It is not to cut other types of material. Do not use the hedge trimmer as a lever to lift, move or break objects. Avoid cutting thick branches, which will damage the blades and shorten the life of the drive system.
HT60D / HT70S Hedgetrimmer Always wear heavy-duty gloves when handling the blades. Blades Check blades for damage before using the hedge trimmer. Clean any residue from the blades using a cleaning agent. Lubricate the blades with spray oil before and after use. Sharpening During the first ten hours of work, avoid running the engine at maximum speed for a prolonged period until all the components have bedded in. After the engine has been run in, it will reach its maximum power.
HT60D / HT70S Hedgetrimmer Safety Lock The safety lock is to prevent the throttle lever from accidentally being engaged. The throttle lever can only be operated, if the safety lock (1) is held down. Check if the safety lock and throttle lever returns to its original position and the engine returns to idling when you release your hand from the handle.
HT60D / HT70S Hedgetrimmer Air Filter Before using the hedge trimmer, check the air filter (3). Being clogged, will reduce the engine performance. Clean the filter element in warm, soapy water, dry completely before installing. If the element is broken or shrunk, replace with a new one. Carburettor The carburettor mixture setting has been set at the factory and will not need adjusting.
HT60D / HT70S Hedgetrimmer Troubleshooting Engine will not start, power loss: • • • • • • 20 Check that the fuel tank is not empty. Fill with mixed fuel. The fuel does not reach the carburettor. Change the fuel filter in the fuel tank. There is water in the fuel. Drain and clean the fuel system. The air filter is dirty. Clean or replace the air filter. There are carbon deposits in the exhaust muffler restricting the engine. Clean or change the muffler. Spark plug is worn. Replace spark plug.
HT60D / HT70S Hedgetrimmer Service Schedule Component Procedure Fuel Leaks / Fuel Spillage Clean Up Fuel Tank.
HT60D / HT70S Hedgetrimmer HT60D Specifications Model..............................................................................................................................................................................................HT60D Type...........................................................................................................................................................................Double Sided Hedgetrimmer Blade length (from the tip of Gear Case).....................
HT60D / HT70S Hedgetrimmer HT70S Specifications Model..............................................................................................................................................................................................HT70S Type...........................................................................................................................................................................Single Sided Hedgetrimmer Blade length (from the tip of Gear Case).....................
HT60D / HT70S Hedgetrimmer HT60D Parts - Engine Unit 24 Original Instructions Version Mar12
HT60D / HT70S Hedgetrimmer HT60D Parts - Engine Unit ID PART NUMBER DESCRIPTION QTY 1 MIGB/T6187.1 M6 HEXAGON NUT WITH FLANGE M6 1 2 MIGB/T70.2 M6X16 PAN HEAD SCREW M6X16 2 3 MIGJB25D.01.00.03 STARTER RATCHET ASSY 2 6 MIGB/T896 4 E-RING SIZE 4 2 7 MIGJB25D.01.10.00-00 FLYWHEEL 1 8 MIGB/T70.1 M5X25 CAP HEAD SCREW M5X25 5 9 MIGB/T93 M5 SPRING WASHER M5 9 10 MIGB/T97.1 M5 WASHER M5 9 11 MIGJB25D.01.00.05-00 OIL SEALS 10X26X5 1 12 MIGB/T893.
HT60D / HT70S Hedgetrimmer HT60D Parts - Engine Unit ID PART NUMBER DESCRIPTION QTY 32 MIYD25.01.03.00-3 NEEDLE BEARING WASHER 2 33 MIYD25.01.03.05-00 NEEDLE BEARING 8X11X9 1 34 MIYD36.01.03.00-4 CIRCLIPS 2 35 MIGJB25D.01.03.02-00 PISTON 1 36 MIGJB25D.01.03.00-2 PISTON PIN 1 37 MIGJB25D.01.03.00-1 PISTON RING 2 38 MIGJB25D.01.00.01-00 CYLINDER GASKET 1 39 MIGB/T70.1 M5X55 CAP SCREW M5X55 2 40 MIGJB25D.01.09.01-00A MUFFLER 1 41 MIGJB25D.01.00.
HT60D / HT70S Hedgetrimmer HT60D Parts - Blade Drive Original Instructions Version Mar12 27
HT60D / HT70S Hedgetrimmer HT60D Parts - Blade Drive ID PART NUMBER DESCRIPTION QTY 1 MIGJB25D.04.00-8 CLUTCH DRUM 1 2 MIGB/T97.1 M5 WASHER M5 15 3 MIGB/T93 M5 SPRING WASHER M5 15 4 MIGB/T818 M5X12 SCREW M5X12 2 5 MIGJB25D.04.00-4 GEAR CASE 1 6 MIGB/T97.1 M6 FLAT WASHER M6 4 7 MIGB/T93 M6 LOCK WASHER M6 3 8 MIGB/T70.1 M6X22 SCREW M6X22 3 9 MIGJB25D.04.00-9 GEAR CASE GASKET 1 10 MIGJB25D.04.00-6 LINK ROD PLATE 2 11 MIGJB25D.04.
HT60D / HT70S Hedgetrimmer HT60D Parts - Blade Drive ID PART NUMBER DESCRIPTION QTY 29 MIGJB25D.06.00-3 BUSH 8 30 MIGJB25D.06.01-00 BLADE 2 31 MIGB/T6186 M5 NUT M5 6 32 MIGJB25D.06.00-4 TOOTHED PLATE 1 33 MIGJB25D.06.00-1 TOP PLATE 1 34 MIGJB25D.06.00-5 BLADE WASHER PLATE 1 35 MIGJB25D.07.
HT60D / HT70S Hedgetrimmer HT60D Parts - Main Body 30 Original Instructions Version Mar12
HT60D / HT70S Hedgetrimmer HT60D Parts - Main Body ID PART NUMBER DESCRIPTION QTY 1 MIGJB25D.00.00-8 FRONT HANDLE 1 2 MIGB/T845 ST4.8X25 TAPPING SCREW ST4.8X25 2 3 MIGJB25D-2.00.00-3 MUFFLER COVER 1 4 MIGJB25D.00.00-10 FRONT ABSORBER SPRING 2 5 MIGB/T96 M5 WASHER M5 5 6 MIGB/T93 M5 SPRING WASHER M5 4 7 MIGB/T70.1 M5X14 CAP HEAD SCREW M5X14 4 8 MIGJB25D.00.00-9 BASE 1 9 MIGJB25D.00.00-11 REAR ABSORBER SPRING 2 10 MIGJB25D.00.00-12 SPRING BLOCK 2 11 MIGB/T845 ST4.
HT60D / HT70S Hedgetrimmer HT60D Parts - Main Body ID PART NUMBER DESCRIPTION QTY 31 MITBC431D.01.13.01 FUEL CAP ASSY 1 32 MIYD45.03.03-00 FUEL FILTER 1 33 MITBC431D.01.13.00-3 FUEL GROMMET 1 34 MITBC431D.01.13.00-6 FUEL PIPE 2.5×5×95 1 35 MIGJB25D-2.03.00-2 FUEL PIPE 1 36 MIGJB25D-2.03.00-3 RETURN PIPE 1 37 MIGJB25D.00.01-00 CORD SPLINT 1 38 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 1 39 MIYD38-3.03.06-00 BREATHER ASSEMBLY 1 40 MIYD38-3.00.
HT60D / HT70S Hedgetrimmer HT70S Parts - Engine Unit Original Instructions Version Mar12 33
HT60D / HT70S Hedgetrimmer HT70S Parts - Engine Unit ID PART NUMBER DESCRIPTION QTY 1 MIGB/T6187.1 M6 HEXAGON NUT WITH FLANGE M6 1 2 MIGB/T70.2 M6X16 PAN HEAD SCREW M6X16 2 3 MIGJB25D.01.00.03 STARTER RATCHET ASSY 2 6 MIGB/T896 4 E-RING SIZE 4 2 7 MIGJB25D.01.10.00-00 ROTOR WHEEL 1 8 MIGB/T70.1 M5X25 CAP HEAD SCREW M5X25 5 9 MIGB/T93 M5 SPRING WASHER M5 9 10 MIGB/T97.1 M5 WASHER M5 9 11 MIGJB25D.01.00.05-00 OIL SEALS 10X26X5 1 12 MIGB/T893.
HT60D / HT70S Hedgetrimmer HT70S Parts - Engine Unit ID PART NUMBER DESCRIPTION QTY 31 MIYD25.01.00.00-2 IGNITION GASKET 2 32 MIYD25.01.03.00-3 NEEDLE BEARING WASHER 2 33 MIYD25.01.03.05-00 NEEDLE BEARING 8X11X9 1 34 MIYD36.01.03.00-4 CIRCLIPS 2 35 MIGJB25D.01.03.02-00 PISTON 1 36 MIGJB25D.01.03.00-2 PISTON PIN 1 37 MIGJB25D.01.03.00-1 PISTON RING 2 38 MIGJB25D.01.00.01-00 CYLINDER GASKET 1 39 MIGB/T70.1 M5X55 CAP SCREW M5X55 2 40 MIGJB25S.01.09.
HT60D / HT70S Hedgetrimmer HT70S Parts - Blade Drive 36 Original Instructions Version Mar12
HT60D / HT70S Hedgetrimmer HT70S Parts - Blade Drive ID PART NUMBER DESCRIPTION QTY 1 MIGJB25D.04.00-8 CLUTCH DRUM 1 2 MIGJB25D.04.01-00 GREASE NIPPLE 1 3 MIGJB25D.04.00-4 GEAR CASE 1 4 MIGJB25S.00.02-00 THROTTLE CABLE SPLINT 1 5 MIGB/T97.1 M6 FLAT WASHER M6 3 6 MIGB/T93 M6 LOCK WASHER M6 4 7 MIGB/T70.1 M6X22 SCREW M6X22 3 8 MIGB/T276 6001-2Z BEARING 6001-2Z 12X28X8 2 9 MIGJB25D.04.00-9 GEAR CASE GASKET 1 10 MIGJB25D.04.00-6 LINK ROD PLATE 2 11 MIGB/T893.
HT60D / HT70S Hedgetrimmer HT70S Parts - Blade Drive ID PART NUMBER DESCRIPTION QTY 29 MIGJB25S.06.01-00 TOP BLADE 1 30 MIGJB25S.06.02-00 BOTTOM BLADE 1 31 MIGJB25S.06.00-1 TOP PLATE 1 32 MIGJB25S.07.00-2 BLADE COVER 1 33 MIGB/T70.1 M5X10 SCREW M5X10 4 34 MIGJB25S.06.00-6 BAFFLE PLATE 1 35 MIGJB25D.06.00-5 BLADE WASHER PLATE 1 36 MIGJB25S.06.03-00 FRONT HANDLE 1 37 MIGJB25S.06.
HT60D / HT70S Hedgetrimmer HT70S Parts - Main Body Original Instructions Version Mar12 39
HT60D / HT70S Hedgetrimmer HT70S Parts - Main Body ID PART NUMBER DESCRIPTION QTY 1 MIGJB25D-2.00.00-3 MUFFLER COVER 1 2 MIGB/T818 M5X12 SCREW M5X12 1 3 MIGB/T845 ST4.2X14 TAPPING SCREW ST4.2X14 10 4 MIGJB25S.00.00-15 HANDLE LOWER BRACKET 1 5 MIGJB25S.00.00-17 SPACER SLEAVE 2 6 MIGJB25S.00.00-16 HANDLE UPPER BLOCK 4 7 MIGB/T70.1 M5X45 SCREW M5X45 2 8 MIGB/T93 M5 SPRING WASHER M5 4 9 MIGJB25S.00.00-18 WASHER 2 10 MIGB/T6186 M5 NUT M5 3 11 MIGJB25S.05.
HT60D / HT70S Hedgetrimmer HT70S Parts - Main Body ID PART NUMBER DESCRIPTION QTY 31 MIGJB25D.00.00-5 FUEL TANK ABSORBER 2 32 MITBC431D.01.13.01-2 STOPPER 1 33 MITBC431D.01.13.01 FUEL CAP ASSY 1 35 MIGJB25D.00.00-7 WASHER 1 36 MIYD45.03.03-00 FUEL FILTER 1 37 MIGJB25D-2.03.00-2 FUEL PIPE 1 38 MIGJB25D-2.03.00-3 RETURN PIPE 1 39 MITBC431D.01.13.00-6 FUEL PIPE 2.5×5×95 1 40 MITBC431D.01.13.00-3 GROMMET 1 41 MIYD38-3.00.00-17 OIL PIPE CIRCLIP 1 42 MIYD38-3.03.
HT60D / HT70S Hedgetrimmer CONDITIONS OF WARRANTY The manufacturer warrants the product against faulty materials and workmanship for a period of 2 years from the date of first purchase. The warranty is applicable when the product is used in a “home owner” application. If products are used for commercial or professional purposes, the warranty period is for 3 months from the date of first purchase. Warranty does not extend to failure due to fair wear and tear.
