User Manual

WRM2
Wireless Remote Monitoring System
www.mirion-hp.com
TECHNICAL SPECIFICATIONS:
Operating Characteristics
Transmit Power Output 100 mW(900 MHz), 50 mW(2.4 GHz)
Receiver Sensitivity -110 dBm(900 MHz) and –105 dBm(2.4 GHz)
Frequencies 900 (910-917) MHz or 2.4 GHz spread spectrum hopper
Over the air data stream: 19,200 BAUD
Addressable Range: from 0 to 65,000
Programmable transmission intervals from 1 sec to 16 sec.
FCC approved, IC Certied, 2.4 GHz unit is CE marked.
Gamma and beta gamma dosimeter compatible
Electrical Characteristics
Battery Type
Battery Life
External Power
PAM-TRX
1.5 VDC AA alkaline
35+ hours
3 VDC std 1.3 x 3.5mm coax
Base Transceiver
1.5 VDC AAA NiMH
4-8 hours
15 VAC 1A Coax center + pin
MESH Repeater/EXT
9 VDC Alkaline
4-8 hours
15 VAC 1A Coax center + pin
IMUX
1.2 VDC AA NIMH
24+ hours
5 VDC 2.5A MUX connector
Mechanical Characteristics
Height
Width
Thickness
Weight
PAM-TRX
4.6” (120mm)
2.6” (65mm)
1.3” (32mm)
7.7oz (220g) w/bat & DMC
Base Transceiver
1.5” (40mm)
5.5” (140mm)
9.5” (235mm)
30 oz (850g) w/batteries
MESH Repeater/EXT
1.2” (30mm)
2.75” (70mm)
5.5” (150mm)
11oz (310g) w/bat & antenna)
IMUX
4.5” (115mm)
2.6” (65mm)
1.6” (41mm)
12oz (340g) w/batteries
Physical Characteristics
Buzzer Frequency
Sound Level
LED’s
Vibration
Controls
Ruggedness
PAM-TRX
2200+500Hz
>85dB @ 30cm
Top & Front
Standard Pager Type
Push button
6 drops @1.5m on concrete
Base Transceiver
Top Panel
Rotary & slide switches
2 drops @ 1m on concrete
MESH Repeater/EXT
Top Panel
Slide switch
2 drops @ 1m on concrete
IMUX
Front case
2 drops @ 1m on concrete
Physical Characteristics
Operating Temp
Relative Humidity
-10C to 50C (14F to 122F)
less than 99% (without condensation)
