IM 201S
Particulate, Gas & Iodine Monitors
PHYSICAL CHARACTERISTICS
● Radiation detected: gamma
● Detector: 1¼”x1” NaI(TI) scintillator + PMT +
241
Am
source
● Iodine cartridge: 57.7 mm (2.27 in)
● Energy range: 100 keV to 3 MeV
● Typical energy windows: 314 - 414 keV
(
131
I, Eγ 364 keV)
● 1024 channels spectrum
● Typical measurement range: 3.7 to 3.7 10
+6
Bq/m
3
(10
-10
to 10
-4
µCi/cc)
ENVIRONMENTAL CHARACTERISTICS
● Long term temperature:
+10°C to +40°C (+50°F to +104°F)
● Periodic temperature:
-5°C to +55°C (+23°F to +131°F)
● MTBF: > 20 000 hours, with preventive maintenance
● TID: 100 Gy (10
+4
rad)
PNEUMATIC CHARACTERISTICS
● Standard  ow rate: 35 l/min (1.24 scfm)
● Pressure drop: according to the  lter dust loading
MECHANICAL CHARACTERISTICS
● Dimensions: 1280 mm x 830 mm x 680 mm (50.4 in x
32.7 in x 26.8 in)
● Weight: ~ 300 kg (~ 661 lb)
● Color: gray RAL 7030 (decontaminable paint)
● Inlet tube connection: Ø 12 mm OD (1/2 in)
● Outlet tube connection: Ø 12 mm OD (1/2 in)
ELECTRICAL CHARACTERISTICS
● Power supply: refer to possible versions
● Data link outputs: 1 RS232 and 2 isolated RS485
● Alarm relays: 3 SPDT relays
● I/O: 2 isolated analog outputs and 1 isolated analog
input (0/4-20 mA)
SIGNALING
● Alphanumeric display: measurement, status…
● Sound alarm: buzzer 90 dBA at 1 meter
● Visual alarm: 3 lights (red, yellow, green)
REFERENCE STANDARDS
● Nuclear: IEC60761, IEC61171
● Environmental: IEC60780, IEEE323
● Seismic: IEC60980, IEEE344
● EMC: 2006/95/CE and 2004/108/CE, EPRI 102323,
MIL STD 461 E, IEC61000-6-2 and IEC61000-6-4
VERSIONS
● 230 Vac or 230 Vac + 400 Vac 3Ø or 120 Vac
+ 400 Vac 3Ø
● Solenoid check source
● With or without dust  lter holder
● Gas grab sampler ports
ACCESSORIES
● Calibration tools
● Software
● USB converters
● Ethernet
● ESD board
