Specification Sheet

Model Number ETR550LCD ETR700LCD ETR1000LCD ETR1500LCD
General
Apparent Output Power 550VA 700VA 1000VA 1500VA
Active Output Power 330 Watts 420 Watts 600 Watts 900 Watts
Topology Line-Interactive
Type Tower
Agency Approvals cTUVus (Conforms to UL1778, CSA 22.2), CE, FCC Class B
Green Compliance U.S. DOE Energy Star, RoHS 2 (EU Directive 2011/65/EU)
Warranty 3-years Electronics / 2-years Batteries
Equipment Protection Policy Up to $75,000 (Continental U.S. and Canada only)
Input Power Plug/Cable NEMA 5-15P W/6 ft cord
Receptacles (Battery/Surge) Type (4/4) NEMA 5-15R (5/5) NEMA 5-15R
Input
Voltage Range 90VAC to 140VAC
Frequency Range 60Hz ±6Hz
Surge Protection 320 joules
Output
Voltage Default 104VAC to 140VAC
Frequency 60Hz ±6Hz
Efciency (AC-AC) >96% (full load)
Output (On Battery)
Voltage 120VAC
Voltage Regulation Nominal ±5% until low battery warning
Frequency 60Hz ±0.5Hz unless synchronized to line
Wave Form Simulated Sine Wave
Overload Capacity
AC Mode: 110% for 1-minute then shutdown, 150% Shutdown Immediately
DC Mode: 110% for 20-seconds then shutdown, 150% Shutdown Immediately
Protection Over-Current, Short-Circuit Protected and Latching Shutdown
Interface
Communications Port USB (Cable included)
LCD Status Indicators
AC Normal, On Battery, AVR Mode, Overload,
Weak/Bad/Disconnected Battery, Site Wiring Fault, Internal Fault
LCD Meter Display
Input & Output Voltage, Input & Output Frequency, Load Capacity
Bar Graph, KVA/KW, Battery Capacity Bar Graph, Est. Runtime
Audible Alarms
On Battery, Low Battery, Internal Fault, Overload, Weak/Bad/
Disconnected Battery
Battery System
Full Load Runtime (non-linear) 3 min. 3 min. 3 min. 3 min.
Half Load Runtime (non-linear) 12 min. 12 min. 12 min. 12 min.
Hot Swappable Batteries Yes
Battery Module Type BM0063 BM0064 BM0065 BM0066
Typical Recharge Time 8 hours to 90% from a full load discharge
Battery Type
Sealed, Non-Spillable, Maintenance Free, Value Regulated
Lead Acid
Physical
Net Dimensions: L x W x H
11.3 x 3.4 x 11.0”
(288.0 x 87.0 x 280.0 mm)
16.1 x 3.4 x 11.0”
(410.0 x 87.0 x 280.0 mm)
Net Weight: lbs. (Kgs.) 13.9 (6.3) 15.7 / (7.1) 22.0 (10.0) 26.0 (11.8)
Shipping Dimensions: D x W x H
14.2 x 6.2 x 14.4”
(360.0 x 158.0 x 365.0 mm)
19.5 x 6.5 x 14.5”
(495.0 x 164.0 x 369.0 mm)
Shipping Weight: lbs. (Kgs.) 15.0 (6.8) 16.8 (7.6) 23.4 (10.6) 27.3 (12.4)
Entrust LCD Series Specifications & Features
ETR550LCD / ETR700LCD / ETR1000LCD / ETR1500LCD
Para Systems, Inc.
1455 LeMay Drive
Carrollton, TX 75007
800.238.7272 • 972.446.7363
www.minutemanups.com • www.sizemyups.com
© Copyright 2015, Para Systems, Inc. Product specications are subject to change without notice. Minuteman, Platinum Protection Plan,
are registered trademarks of Para Systems, Inc. Entrust LCD and SentryHD are trademarks of Para Systems, Inc. All other trademarks are
the property of their respective holders. All rights reserved.
Publication No. 34000503 (10-2015)
Protects Against Spikes, Surges,
Brownouts and Blackouts
• Automatic Voltage Regulation (AVR)
• Four surge and battery protected outlets
(550/700VA models)
• Four surge-only outlets for protection of non-critical
accessories (550/700VA models)
• Five surge and battery protected outlets
(1000/1500VA models)
• Five surge-only outlets for protection of non-critical
accessories (1000/1500VA models)
• Input circuit breaker protection
Feature-rich Design
• Ultra compact case design
• LCD front panel display
• USB communications
• Hot-swappable batteries
• Easy battery access
• Tool-less battery replacement design
• 3-year limited warranty (electronics), 2-year
warranty (batteries)
• RoHS 2 compliant
• Energy Star certied
• Transformer-friendly receptacles
• DC Startup capability
• Independent Battery Bypass
• Built-in self-diagnostics testing
• Site-wiring fault indicator
• Audio & Visual alarms
• Alarm silencer button
LCD Display provides real-time
information
• UPS status and condition
• Battery Capacity bar graph
• Estimated Runtime
• AC and DC modes
• Load Capacity bar graph
• Warning / Fault icons
Compatible with Minuteman SentryHD
Management Software
• Automatically saves and shuts down unnished
applications
• Gracefully powers down your PC during extended
blackouts
• Provides comprehensive monitoring capabilities
• Integrates into SNMP network (when connected to
a computer via USB port)
