Specification Sheet

The Minuteman Entrust LCD Series UPS provides users all the features usually available in
higher-priced UPS products to protect your valuable equipment: automatic voltage regulation,
spike and surge protection, and battery backup, all in a surprisingly compact package.
Entrust LCD units feature eight to ten total outlets to ensure that all devices in your system can be
protected with one of four or ve surge-only or surge and battery protected outlets. The Entrust
LCD’s compact footprint makes it an ideal solution for cramped spaces including network and
security closets, AV cabinets, tight desks, and more. With sizes ranging from 550VA to 1500VA,
the Entrust LCD can support a wide range of equipment, including personal computers, small to
midsize security DVRs, network devices, small telephone systems, and more.
Entrust LCD Series
550-1500VA AVR Compact Tower UPS
Key Product Line Features
Applications
Communications
Workstations, Small Phone Systems
Security
Midsize DVR, Acc Ctrl, Intrusion
IT/Network
Switches, Hubs, Access Points
Tool-less Battery Panel
Easy-access setup & maintenance
SentryHD Software Compatible
Monitor and manage via USB
3-yr Electronics Warranty
2-yr non-prorated battery
Capacity:
Sm Med Lrg
• Efcient Automatic Voltage Regulation (AVR) Hardware
Regulates output voltage for protection against spikes, surges,
brownouts, and blackouts
• Compact form factor ideal for tight installs
• Protect all of your devices
8-10 power battery backup and surge-only outlets ensure
space for all pieces of the system
• Tool-less Battery Access
Setup and maintenance made easy with tool-less battery
panel
• Efcient, Responsible Power
ENERGY STAR and RoHS 2 Compliant
• Total Control of Your Power
Free download of Minuteman SentryHD management
software connects via USB and provides total monitoring and
management capability
• Independent Battery Bypass
Provides voltage regulation with surge and spike protection,
even when batteries are weak or dead
• Unmatched Peace of Mind
3-year limited warranty (electronics), 2-year warranty (batter-
ies), and Minuteman Platinum Protection Plan™
Complete Protection for:
• Desktop Computers
• Standalone Servers
• Network Switches, Hubs, and Peripherals
• VoIP Communications
• Telephone Systems
• External Computer Accessories
• Security Cameras and DVRs
Key Features
LCD Status Display
Power information in real-time
Trouble-free Setup & Monitoring LCD Display & Easy-access Battery
LCD Control Panel
Monitor your power in real time with Entrust LCD’s control panel.
Tool-less Battery Panel
Setup and maintenance are a breeze with Entrust LCD’s
tool-less battery panel and large easy-grip battery
connector. Simply slide the panel down to access the
battery for initial connection or battery maintenance.
1
2
4
6
5
3
Minuteman Power Technologies | 800.238.7272 | minutemanups.com | sizemyups.com
1
2
3
7
5
6
4
5
6
4
8
87
1 LCD Status Display
2 On/Off/Test, Display Scroll, Alarm
Silence
3 Tool-less battery access panel
4 USB Communication Port
5 Surge-only 5-15R outlets
(4 - 550 & 700, 5 - 1000 & 1500)
6 Battery Backup & Surge 5-15R Outlets
(4 - 550 & 700, 5 - 1000 & 1500)
7 6-ft. Power Cord
8 Input Circuit Breaker
5R+6

&203/,$17
1 Unit Status Indicator
2 Load and Battery Meters
3 Numeric Display
4 Display Scroll Button
5 Alarm Silence Button
6 On/Off/Test Button
Specs, video, & more at minutemanups.com/entrustlcd
