User's Manual

50 5150 51
English
Model 1-5x24 2-10x50 3-15x56 5-25x56 LR
Magnification 1– 5 x 2 – 10 x 3 – 15 x 5 – 25 x
Objective diameter (mm) 24 50 56 56
Exit pupil diameter low / high (mm) 11,4 / 4,9 11,4 / 5,2 11,4 / 3,8 10,6/ 2,3
Field of view / meters at 100 meters 37,1 / 8,2 18,9 / 4,0 11,9 / 2,3 7,2 / 1,6
Eye relief (mm) ~ 100 ~ 100 ~ 100 ~ 95
Diopter adjustment range – 3,0 / + 2,5 – 3,0 / + 2,5 – 3,0 / + 2,5 – 4,0 / + 2,2
Elevation and windage adjustage (per click) 1 cm / 100 meters 1 cm / 100 meters 1 cm / 100 meters 1 cm / 100 meters
Reticle adjustment range (elevation and windage) ± 100 cm ± 100 cm ± 55 cm E: ± 140 cm / W: ± 60 cm
Parallax adjustment 100 m 100 m 50 m to infinity 50 m to infinity
Illuminated reticle Yes Yes Yes Yes
Focal plane 2 2 2 1
Power supply for the illuminated reticle 2 x CR 2032 2 x CR 2032 2 x CR 2032 1x CR 2032
Argon filling Yes Yes Yes Yes
Fogproof and waterproof Yes Yes Yes Yes
Main tube diameter (mm) 30 30 30 34
Overall length (mm) 285 335 372 430
Weight (g) 480 650 760 940
Order number 80107662 | 80107666 (Z-Rail) 80107663 | 80107667 (Z-Rail) 80107664 | 80107672 (Z-Rail) 80107665
TECHNICAL DATA
