LENS PROTECTION CAPS
The MINOX riflescope comes with an eyepiece protection cap
and an objective protection cap. The caps are attached to the
eyepiece respectively to the objective via the adapter ring.
To attach the protection cap, push the lens cap onto the adapter
ring until it snaps into place. To remove the cap, close it and
grab it at the hinge and pull it from the adapter ring. The cap
can be turned on the adapter ring in increments in order to
adjust the position of the opened cap. The cap snaps into place
in the opened position and lies closely against the eyepiece.
Note: If you are not using the eyepiece protective cover,
please use the eyepiece protection ring supplied and press
it onto the eyepiece until it snaps into place.
CARE AND MAINTENANCE
The required maintenance of the tube and controls is limited
to the removal of dust and dirt that can aect the operational
elements of the riflescope. Dust, sand and dirt should be rinsed
o under running water and the scope carefully patted dry with
a clean cloth afterwards.
Note: Do not make any changes to the riflescope other than
those described in these instructions.
Refrain especially from unscrewing or removing elements
as the seals can be damaged or mechanical functions of
the riflescope adversely aected, thus voiding the warranty.
The lenses should be protected by caps or similar to avoid dam-
age and soiling when the riflescope is not in use. The lenses
and seals must not come into contact with oil or solvents. When
cleaning your weapon, make sure that the riflescope is protect-
ed from contact with cleaning agents.
When cleaning the lenses with commercial lens cleaning prod-
ucts, the manufacturer’s instructions must be observed. Clean-
ing cloths and pens must be clean and free of particles as these
may cause damage when rubbed onto the lens surfaces. Coarse
dirt can be rinsed o under running water and the lenses gently
patted dry with a soft cloth. The lenses should only be cleaned
when absolutely necessary.
Note: When rinsing the riflescope under running water,
avoid strong jets of water as this may damage the seals.
TROUBLESHOOTING
Accuracy problems
One of the most common causes for inaccuracy (excessively
large groups, double groups, stringing or flyers) is caused by
improper mounting of the riflescope. Check all mounting com-
ponents for tightness. Furthermore, make sure that the barrel
is free of oil, cleaning agents and excessive fouling by powder
residue and projectile debris. Use ammunition from the same
manufacturer and lot number, and place the weapon on a solid
surface such as a sandbag.
If accuracy problems should persist, please contact a qualified
gunsmith to have your weapon examined.
Fogging
Internal lens surface fogging is the result of broken seals, al-
lowing moisture to enter the scope. If the seal has failed under
normal use, MINOX will repair or replace the scope in accord-
ance with the MINOX warranty terms. However, fogging is most
commonly the result of scope disassembly, which is not covered
by the MINOX warranty.
With any internal fogging, return the scope to your authorized
MINOX dealer or the MINOX service center for repair.
External lens surface fogging
External lens surface fogging is a common problem under the
right temperature and humidity conditions. It cannot be avoid-
ed. Anti-fogging solutions may oer some relief, but simply
wiping with a clean cloth is the most eective treatment. Avoid
breathing on the eyepiece lens in cold weather.
SERIAL NUMBER
The serial number can be found on the underside of the rifle-
scope. Enter this serial number into the online registration form
for the MINOX Comfort Service at www.minox.com/service.
SERVICING
Avoid unnecessary expense and delays by first checking all
the user information and troubleshooting suggestions before
returning your scope for service. If service is required, follow
these instructions to send your MINOX scope directly to the
service center:
1. Pack the scope with adequate packing materials to prevent
damage.
2. Ship your scope prepaid and insured to your authorized
MINOX dealer or local MINOX distributor:
Germany:
MINOX GmbH (Werk 2)
Technischer Service
Wilhelm-Loh-Str. 1
35578 Wetzlar
