User Guide

- 5 -
!
Hold the bike firmly by hand and turn the right side hub handle clockwise until the coupling comes into
contact with the right side skewer nut.
5
6
(Fig. G)
Adjust each height of the Mag unit and the assistant
roller to fit to your rear wheel perfectly and tighten the
bolts firmly. (see Fig. G)
Each rubber roller is made to contact the rim ONLY.Each rubber roller is made to contact the rim ONLY.
Each rubber roller is made to contact the rim ONLY.Each rubber roller is made to contact the rim ONLY.
Each rubber roller is made to contact the rim ONLY.
Contact with the tire may cause the tire to burstContact with the tire may cause the tire to burst
Contact with the tire may cause the tire to burstContact with the tire may cause the tire to burst
Contact with the tire may cause the tire to burst
during use.during use.
during use.during use.
during use.
(Fig. H)
7
Adjust the wheel position by checking the double-circle
position indicators on both side.
The best position should be each indicator can be seen
equally, but if your rim is narrow, you should adjust
the wheel position to be a little left (toward Mag side)
to prevent unexpected slippage problem.
NOTE:NOTE:
NOTE:NOTE:
NOTE: Note that the left side knob is NOT for tightening
the axle. It is only for positioning the wheel. Clamping
wheel securely must be done by the right side hub handle.
USING THE PLATIC SKEWER NUT PROTECTOR
We recommend that you use the supplied skewer if at all possible. This
will gaurantee a fit with our couplings and remove any chance of mis-
alignment.
(Fig. I)
The right side coupling has a black plastic skewer nut protector (called a “Grommet”). This is to protect your
skewer from damage during use, however, should you choose to use your own skewer, you should use the
supplied grommet to insure a better fit.
We will NOT guarantee any fitting problem or accident caused by using your own skewer on the trainer.We will NOT guarantee any fitting problem or accident caused by using your own skewer on the trainer.
We will NOT guarantee any fitting problem or accident caused by using your own skewer on the trainer.We will NOT guarantee any fitting problem or accident caused by using your own skewer on the trainer.
We will NOT guarantee any fitting problem or accident caused by using your own skewer on the trainer.
When you use the supplied skewer, you should remove the grommet from the coupling. It can be done by
inserting a rod or a pen to the hole (see Fig. I) and then lifting up the grommet.
Hole
