SNMP Events Table
98 | Smart 108/116 IP
Event Text Code Comment
Wrong user name
or password
2030 Wrong user name or password. Login is not successful.
CONF_USER_EVENT_LOGIN_NOT_SUCCEEDED_WRONG_USER_NAME_O
R_PASSWOR D
Login is not
successful
because server is
busy.
2040 Login is not successful because server is busy.
CONF_USER_EVENT_LOGIN_NOT_SUCCEEDED_SERVER_BUSY
DHCP server
setting has been
changed
2060 DHCP server setting has been changed. CONF_DHCP_CHANGED
Network IP
address changed
2070 Network IP address has been changed. CONF_IP_CHANGED
Network Subnet
Mask changed
2080 Network Subnet Mask has been changed. CONF_SNMASK_CHANGED
Network Default
Gateway changed
2090 Network Default Gateway has been changed. CONF_DG_CHANGED
User Logged out
from Config
2100 User Logged out from Config. CONF_LOG_OUT
TCP Port was
changed
2110 TCP Port was changed. CONF_TCP_PORT_CHANGED
Remote Access
type was changed
2120 Remote Access type was changed. CONF_REMOTE_ACCESS_CHANGED
Security settings
changed
2140 CONF_SECURITY_CHANGED
Restore default
factory settings
successful
2150 CONF_RESTORE_FACTORY_OK
Restore default
factory settings
failed
2160 CONF_RESTORE_FACTORY_FAILED
Firmware Upgrade
successful
2170 CONF_UPGRADE_OK
Firmware Upgrade
failed
2180 CONF_UPGRADE_FAILED
