Technical Specifications
User Guide | 95
Specification Description
Supported colors
16.7 M
Keyboard/mouse
106 key PS/2 keyboard with touchpad
Sync
45 ~ 80HZ
Power source
100-240 VAC input
Response time
Rising time 2-6 ms; Delay time 14-24 ms
Rack depth support
468.9 to 814 mm / 18.46x32.047
Chassis construction
Heavy duty steel
Power supply
Internal switching 85-260 VAC 50/60 Hz
Specification ROC PS/2 ROC USB
Connections VGA – HDD15
KM – MiniDin6
System – RJ45
VGA – HDD15
KM – USB
System - RJ45
Power
From Keyboard port From USB port
Product Weight
100 g / 0.20 lb
Shipping Weight
172 g / 0.38 lb
Dimensions (H x D x W)
65 x 25 x 25 mm / 2.55 x 0.98 x 0.98 in
