Operating the SmartRack 116 IP Switching System Locally
Troubleshooting – Update Software
User Guide | 91
Manually Updating the RICC/ROCs
You can manually update the RICC/ROCs after starting the Update software.
To manually update the RICC/ROCs:
1. Select one or more ROCs..
2. Press
Options -> Advanced -> Manual Update.
3. Open the appropriate hex file.
4. Click Start.
The firmware updates.
6.3.9 Restoring Factory Settings
You can restore the OSD to the factory settings from the Update software.
All changes made (such as passwords, access rights, and names) will be
removed.
To restore the OSD factory settings:
1. Select Options/Advanced/Set default.
The OSD returns to the factory default settings.
You can also restore the OSD default settings from the OSD (F7) (see page 77)
6.4 Troubleshooting – Update Software
This section describes how to troubleshoot the following problems that may arise
when updating the SmartRack 116 IP firmware:
Unit hangs or mouse malfunctions
Break in communication
Communication Error message
Electricity failure
