Operating the SmartRack 116 IP Switching System Locally
Using the OSD
74 | SmartRack 116 IP
6.2.3 Configuring the OSD Settings
You can configure the following OSD settings:
General (see Section 6.2.4)
Ports (see S
ection 6.2.5)
Time (see Section 6.2.6)
Users (see
Section 6.2.7)
Security (se
e Section 6.2.8)
You can also view the
available Help (see Section 6.2.9).
To configure the OSD settings:
1. Press F2.
The OSD Settings window appears.
Figure 75 – OSD Settings Window
When the OSD is password protected (explained below), only the Administrator
has access to the F2 settings window.
6.2.4 Configuring the General Settings
From the General Settings screen, you can configure the following general settings:
Security
OSD hotkey
Autoskip
