Operating the SmartRack 116 IP Switching System Locally
Using the Keyboard Hotkeys
72 | SmartRack 116 IP
6 Operating the SmartRack 116 IP
Switching System Locally
This chapter explains how to operate the SmartRack 116 IP Switching system locally,
as well as how to upgrade the SmartRack 116 IP firmware (see Section 6.3) and
troubleshoot problems that arise when
updating the software (see Section 6.4).
You ca
n switch between the connected computers using either the:
Keyboard hotkeys
The OSD (On Screen Display)
With a US English keyboard, you can use the + key of the alphanumeric section
or of the numeric keypad. With a non-US English keyboard, only use the + key
of the numeric keypad.
6.1 Using the Keyboard Hotkeys
You can switch to the next computer in the forwards or backwards direction.
To switch to the next computer forwards:
1. Press Shift.
2. Release Shift and then press +.
To switch to the next computer backwards:
1. Press Shift.
2. Release Shift and then press -.
6.2 Using the OSD
To display the OSD:
1. Ensure that there is no remote user connected.
If there is a remote user, disconnect the remote user by pressing the Local button
on the SmartRack 116 IP.
2. Press Shift twice.
The OSD Main window appears.
