Troubleshooting – Safe Mode
Restoring Factory Defaults
70 | SmartRack 116 IP
5.2 Restoring Factory Defaults
You can restore all SmartRack 116 IP settings to their default values.
To restore factory defaults:
1. In the Safe Mode menu (see Figure 69), click Restor
e Factory Settings.
A warning appears.
Figure 70 – Warning
2. Click
.
An additional warning appears.
Figure 71 – Additional Warning
3. Click OK
.
The factory defaults are restored. When the process finishes, the following figure
appears.
Figure 72 – Reboot
4. Click Reboot to restart the unit.
5.3 Restoring the Device Firmware
To receive the Upgrade firmware required to restore the device firmware, contact
Minicom Technical Support
support@minicom.com. Save the Upgrade firmware on
the hard disk of a computer connected to the network.
