Configuring the Network
Performing Additional Configuration Operations
User Guide | 43
3.8 Performing Additional Configuration Operations
You can perform the following additional operations on SmartRack 116 IP:
Install an SSL certificate.
Upgrade firmware.
Restore factory settings.
3.8.1 Installing an SSL Certificate
You can install an SSL Certificate, to ensure secure transactions between the Web
servers and browsers.
To install an SSL Certificate:
1. In the toolbar, select
.
The SSL Certificate page appears.
Figure 44 – SSL Certificate Page
2. In Certificate file, browse to locate the Cer file.
3. In Private key file, locate the private key file in Microsoft pvk format.
4. In Key password, type the password required to upload the Private Key file.
Each Private Key file is generated with a unique password.
5. Click Install.
The SSL Certificate is installed.
