User guide

Installation
System Components
User Guide | 17
Figure 1 – Rails
 Long bracket x 2. (For increased rack depth of 905 ~ 990mm)
Figure 2 – Long Brackets
 Short bracket x 2
Figure 3 – Short Bracket
 Bracket attachment x 2
Figure 4 – Bracket Attachment
The short bracket and bracket attachment are for a rack depth of 504 ~ 614
mm and without a KVM switch connected to the drawer.
 Flat screws x 6 (for rail mount to console body)
Figure 5 – Flat Screw
