24. Technical specifications
System
Operating systems Novell, LINUX, Windows, UNIX SUN, MAC and other major
operating systems
Resolution 1600 X1200 @75Hz
User to server
distance
200m/660ft
System cable CAT5, CAT6, CAT7
Operating temp. 0° to 40°C/32° to 104°F
Storage temp. -40°C to 40°C/-40°F to 104°F
Security Password, multiple User Profiles
Management Multilingual AIM Advanced Integrated Management,
Mouse Support PS/2, Wheel mouse, 5-button mouse, Microsoft intellimouse
Warranty 3 Years
DX units
DX Central Unit DX User Unit DXU IP
Cables/Connectors Server Ports –
32 RJ45
Users – 4/8
RJ45
Serial – 2 X DB9
LAN – RJ45
Power
System – RJ45
Local Console and
CPU KVM + Serial
Video – HDD15
K/M – MiniDin6
Serial – 2 X DB9
Power
2 X USB
System – RJ45
Local Console +
Serial
Video – HDD15
K/M – MiniDin6
Serial – 2 X DB9
LAN – RJ45
Power
2 X USB
Rack Mountable Yes
Dimensions 43.2x27x4cm /
17X11X1.6”
21.6x27x4cm /
8.5X11X1.6”
43.2x27x4cm /
17X11X1.6”
Power supply
input rating
100 – 250 VAC 50/60 Hz
