7.6 Connecting servers/devices in a cascaded system
You can connect servers/devices to any available Server port on any level DX
Central.
8. Powering on the system
The devices and servers can be powered on at any time. Power on the DX
components in the following order:
1. The primary and secondary level DX Centrals.
2. The DX Users.
9. Configuration wizard (non-DX cascaded system)
For cascaded DX systems, skip to section 10.
The first time the system is connected and powered on, the Configuration Wizard
box appears on the screen of the DX User. See Figure 22.
Figure 22 Configuration Wizard box
1. Click Single DX configuration.
2. Click , then click . The Login screen appears, see below.
