Installation manual

Ilumen
3
Installation Manual Ilumen PIDbox Mini v1.5
1 INFORMATION ON THIS MANUAL
This manual contains instructions on how to install the Ilumen PIDbox mini.
1.1 VALIDITY
This manual applies to the Ilumen PIDbox mini v1.5.
1.2 TARGET GROUP
This manual is intended for skilled persons. Only qualified persons with the appropriate skills
are allowed to perform the tasks set forth in this manual.
1.3 ADDITIONAL INFORMATION
Links to additional information can be found at www.ilumen.be
 Ilumen PIDbox mini datasheet
 What is PID?
 PID checker
1.4 SYMBOLS
Symbol
Explanation
Indicates a hazardous situation which, if not avoided, will result in
property damage
Indicates a hazardous situation which, if not avoided, will result in death
or serious injury
Information that is important for a specific topic or objective, but is not
safety-relevant
2 SAFETY
2.1 APPROPRIATE USAGE
The Ilumen PIDbox mini applies a voltage to PV modules in reference to earth. The device may
only be switched on when the installation is done as described in this manual.
Before installing the Ilumen PIDbox mini, ensure that the permitted operating range of each
component is maintained at all times.
Before using the Ilumen PIDbox mini you have to obtain the appropriate approval from the
manufacturer of the PV modules.
Any applications other than those described here shall be considered contrary to the
appropriate usage. Alternative use or modification of the Ilumen PIDbox mini will void warranty
claims and operation permit.
