Installation Manual Ilumen PIDbox Mini v1.5
9.3 DISPOSING OF THE PIDBOX MINI
Dispose of the PIDbox mini at the end of its service life in accordance with the disposal
regulations for electronic waste currently applicable at the installation site.
10 TROUBLESHOOTING
10.1 FAULTS
LED readout
Fault
Corrective action
No leds visible
Product does not work
Make sure the DC-power supply is
plugged into a AC-outlet. Also make
sure the outlet is under tension.
No leds visible
Product does work and
makes some clicking noises
This can happens at dusk and dawn.
LED should light up after a while. If not
please contact iLumen technical service.
Led gives other color
than BLUE, GREEN,
CYAN or RED
Product does not work
Please contact iLumen technical service.
No red led during
nighttime while during
the day blue or cyan
leds are burning
Curing of the panels is not
working
This can have 2 reasons:
 PID is not present on PV-
modules (however the first
night of regeneration the led
must be on).
 Earth connection between
PIDbox mini and the frame of
the modules is interrupted
10.2 NO GOOD PID REGENERATION
If the modules are not regenerating or not regenerating fast enough you should check following
things:
 Check the grounding of the system. If necessary you should place additional
interconnections between the frames of the modules.
 Is the Ilumen PIDbox mini properly connected to the grid?
 Is the DC power supply properly connected (is its indication light burning)?
 Let an expert check if the problem you’re having with the yield is caused by PID
10.3 RESETTING THE PIDBOX MINI
The PIDbox mini can simply be reset by unplugging the DC-power cable. Wait 10 seconds and
connect the DC-power cable back to the PIDbox mini.
If resetting does not help fixing your problem, please consult chapter 10.1 of this manual.
10.4 REPAIRING THE PIDBOX MINI
Do not try to open up the PIDbox mini by yourself. The warranty will be void.
