Patient Setup Functions Transfer Tab
5. Select the Central To Central Without Device button. The Select Destination
Panorama list box (FIGURE 5-11) is displayed.
FIGURE 5-11 Select Destination Panorama List Box
6. Select the Destination Panorama device from the Select Destination Panorama list
box.
• Select the Done button. The message Are you sure you want to transfer the
selected patient? is displayed with the following two choices:
• Select the Yes button to initiate the first part of the transfer process and return to the
Transfer tab. In the Transfer tab, the message Central Transfer in progress
displays next to the Central To Central Without Device button, which has been
disabled.
• Select the No button to terminate the transfer and return to the Transfer tab.
• Select the Cancel button to terminate the transfer and return to the Transfer tab.
If the transfer process is initiated, it will continue as described in “Destination Panorama”. As
the transfer process continues, the procedure will refer to messages and a progress bar that
will display at the Source Panorama.
5.2.3.2 Destination Panorama
When a Central To Central Transfer Without Device has been requested from
another Panorama, the message Transfer In Request from [the Source Panorama
name]. Accept/Reject in Transfer Dialog displays in the system status line of the
Destination Panorama.
1. At the Destination Panorama, select a tile that has a device attached.
2. From the menu bar, select the Patient Setup menu button. The tabs associated with
patient setup display.
